20 VM1 Vacuum circuit-breaker | Instruction manual 504/05
7.6.2 Auxiliary materials and lubricants
Designation Part no.
(order code)
Lubricant:
- Isoflex Topas NB 52 GCE0007249P0100
Halogen-free cleansers:
- Rivolta BWR 210 GCE0007707P0100
(for general cleaning)
- ABB Instruction manual
BA 1002/E GCEA901002P0102
Table: VM1 withdrawable part
- Cold cleanser 716 GCE0007706P0100
(for use with conductive components,
components of insulating materials
and in case of serious grime!)
- ABB Instruction manual
BA 1006/E GCEA901006P0102
Paint:
- Touch-up paint:
Standard colour RAL 7035
- 1 kg-box GCE9014060R0103
- Spray tin GCE0007895P0100
Designation
Item
no.
Rated supply
voltage
Part no.
(order code)
Auxiliary switch for manually operated mechanism
- contacts silver plated
- contacts gold plated
-BT2 / -BT1
GCE7004024R0101
GCE7004024R0103
Auxiliary switches for motor-operated driving mechanism
- contacts silver plated
- contacts gold plated
-BT2 / -BT1
GCE7004024R0102
GCE7004024R0104
Blocking magnet -RL2 24 V
30 V
48 V
60 V
110 V
125 V
220 V
GCE7003820R0101
GCE7003820R0102
GCE7003820R0103
GCE7003820R0104
GCE7003820R0105
GCE7003820R0107
GCE7003820R0106
Motor with gearbox -M1 24 V
30 V
48 V
60 V
110 V … 125 V
220 V
GCE0940150R0111
GCE0940150R0112
GCE0940150R0113
GCE0940150R0114
GCE0940150R0115
GCE0940150R0116
Table: VM1 type circuit-breaker
Designation Item no.
Part no.
(order code)
Auxiliary switch for ON/OFF
position signalization
- Silver-plated contacts
- Gold-plated contacts
-BB1 / -BB3
GCE7002397R0119
GCE7002397R0125
Designation
Rated supply voltage- Part no.
(order code) up to 40 kA 50 kA
Breaker controller
Power pack A
- Standardversion
- Fullversion
- 24 V … 48 V AC
- 24 V … 60 V DC
GCE7004902
GCE7004902
R0120
R0126 R0126
Breaker controller
Power pack B
- Standardversion
- Fullversion
- 100 V … 240 V AC
- 110 V … 240 V DC
GCE7004902
GCE7004902
R0121
R0127 R0127
BA 504-05 GB_29102012.indd 20 30.10.12 13:44
