Instruction manual 504/05 | VM1 Vacuum circuit-breaker 35
10.2 Technical data
Circuit-breakers for fixed installation
10.2.1 Performance data and weights
Guideline values for function times:
Closing time ca. 45…60 ms
Opening time ca. 35…50 ms
Arcing time (at 50 Hz) ≤ 15 ms
Break time ≤ 60 ms
Minimum command time on closing 20 ms
Minimum command time on opening 20 ms
1)
At operating voltages lower than the rated voltage, the same values fundamentally apply as for the rated voltage. Higher values on request.
2)
Individual unit without truck
3)
Breakers for 4000 A with fan cooling
Breaker
type
Rated
voltage
Rated
current
Rated
short-
circuit-
breaking
current
symm.
1)
Short-
circuit
breaking
currentr
asymm.
1)
Rated
short-
circuit
making
current
(peak)
1)
Rated
short-
circuit
duration
Pole
centres
Weight
2)
Permissible
number
of vacuum
interrupter
switching
operations
Dimen-
sional
drawings
VM1.. kV A kA kA kA s mm approx.
kg
Figure
10a/10b
Page 33/34
Figure-no.
1231-25 12 3150 25 27.3 63 3 275 235 Diagram C 10/2
1240-25
3)
4000
3)
275 235 Diagram C 10/2
1231-31 3150 31.5 34.3 80 3 275 235 Diagram D 10/2
1240-31
3)
4000
3)
275 235 Diagram D 10/2
1212-40 1250 40 43.6 100 3 210 135 Diagram E 10/1
1216-40 1600 210/275 135/142 Diagram E 10/1
1220-40 2000 210/275 135/142 Diagram E 10/2
1225-40 2500 210/275 141/148 Diagram E 10/2
1231-40 3150 275 235 Diagram E 10/2
1240-40
3)
4000
3)
275 235 Diagram E 10/2
1212-50 1250 50 54.5 125 3 210/275 232/240 Diagram F 10/3
1216-50 1600 210/275 232/240 Diagram F 10/3
1220-50 2000 210/275 232/240 Diagram F 10/3
1225-50 2500 210/275 232/240 Diagram F 10/3
1231-50 3150 275 245 Diagram F 10/3
1240-50
3)
4000
3)
275 245 Diagram F 10/3
Rated voltage kV 12 17.5
Rated frequency Hz 50/60 50/60
Rated lightning impulse withstand voltage kV 75 95
Rated power frequency withstand voltage kV 28 38
Rated of rise of transient recovery voltage kV/µs 0.34 0.42
Peak transient recovery voltage kV 20,6 30
Rated operating sequence O-3 min-CO-3 min-CO
Rated operating sequence for autoreclosing O-0,3 s-CO-3 min-CO
