Acer A100 User Manual

1-26 Hardware Specifications and Configurations
USB Port
HDMI Port
AC Adapter
System Power Management
Item Specification
USB compliance level USB2.0
Protocol EHCI
Number of USB port(s) 1
Location one at the right side
Output Current
Item Specification
Compliance level HDMI1.3a
Data throughput Up to 16.7 million colors
Number of HDMI port(s) 1
Location one at the right side
Item Specification
Input rating 18W
Maximum input AC current 0.5A(RMS) at 100Vac
Inrush current 60A Max. @230Vac
Efficiency Refer to EPS 2.0 standard level V
Item Specification
Mech. Off (G3) Only EC working.
Soft Off (G2/S5) Only EC working.
Working (G0/S0) Individual devices such as the CPU and eMMC may be power
managed in this state.
Suspend to RAM (S3)
 CPU suspend
 Audio Power Down
 eMMC Power Down
 LCD power off
 MIC power off
Save to Disk (S4) N/A

Acer A100 Specifications

General

Display	7-inch TFT LCD, 1024x600 resolution
RAM	1 GB
Internal Storage	8GB or 16GB
Rear Camera	5 MP
Front Camera	2 MP
Dimensions	195 x 117 x 13.1 mm
Weight	410 g
Connectivity	Wi-Fi 802.11 b/g/n, Bluetooth 2.1, microUSB 2.0
Processor	NVIDIA Tegra 2 dual-core 1GHz
Operating System	Android 3.2 (Honeycomb), upgradable to 4.0 (Ice Cream Sandwich)
Battery	1530 mAh
