3.1 Packing Exploded Diagram
3. Exploded Diagram
1-1
5-1
1-3
1-2
1-4
2
3-1
3-2
4
6
9
7
8
10
12
13
15
16-1
18
11
16-2
17
14
SUB-ITEM
PART NO.
DESCRIPTION Q'TY
1
7737515700P0A
FRONT COVER ASSY 1
2-1
7737612100P0A
REAR COVER ASSY 1
2-2
7742238700P0A
FRONT COVER 1
2
FUNCTION KEY 1
3
7742302790P0A
LENS 1
4
FUNCTION KEY PCB 1
5
PANEL-AUO-M154EW01 V0 1
6
7110330052P0A
SCREW(FIXED PANEL) 4
7
7737811320P0A
BRACKET CHASSIS BASE ASSY
1
8
7748713920P0A
BRACKET CHASSIS BASE 1
9
7746504790P0A
INSULATOR-TOP 1
5113302551P INTERFACE PCB
1
10
7111230061P0A
SCREW(FIXED POWER BD)
11
5114301021P POWER PCB
1
7111230061P0A SCREW(FIXED INTERFACE BD) 3
12
13
7140130061P0A
SCREW
14
7738001300P0A
HINGE
1
15
BASE
1
16 1
7115240121P0A
SCREW (FIXED HINGE) 4
2-4
7742807870P0A
6-1
6-2
684152020P191
2
7740412200P0A
HINGE STAND
5113800899P
7742238600P0A
REAR COVER 1
7749600940P0A
TAPE PACKING ACER LOGO 1
2-3
POWER KNOB 1
7742807880P0A
7742612091P0A
BASE ASSY
7740412200P0A
116-1
16-2
16-3
RUBBER
7742004160P0A
4
TAPE PACKING ACER LOGO
7749600950P0A
1
7116240081P0A
SCREW(FIXED GROUND) 1
3
5-1
5-2
18
7742613400P0A
COVER HINGE 1
17
7140340162P0A
3
SCREW
10
