Acer AL1516W User Manual

Use a Phillips-head screwdriver unscrew 4 screws
to release the stand base.
(No1~4 Screw Size=M4x12;
Torque=12~14KGFxCM).
Disassemble the hinge cover.
P
ut returned unit on a protective cushion,then
remove LDPE+EPE bag.
Tear off tapes to remove the screen protector
card then turn over the LCD monitor (screen
faced down),
Take off two cushion foams
Take out all accessories including D-SUB cable
power cable, user’s manual, and packing material
from the carton.
(Note: It depends on whether users returning
the accessories.)
Open the carton with a proper tool.
Turn over the LCD monitor (screen faced up).
S6
S5
S4
S3
S2
S1
S7
4.2 Disassembly procedures
VISTA LABEL
VGA CABLE
1
2
3
4
16
Go to cover page
4. Assembly and Disassembly Procedures (continued)
ACER AL1516W
