3-14 Machine Maintenance
4. Remove the two screws securing the HDD bracket.
Figure 3-13. HDD Bracket Screws
5. Detach the bracket from the HDD module.
Figure 3-14. HDD Bracket
Table 3-13. Screws
Step Screw Quantity Screw Type
HDD Bracket Disassembly M3 × L4 2
