1.3
Jumpers and
Connectors
1.3.1
Jumper and Connector Locations
Figure 1-2 shows the jum
per and connector
locations on the system board.
Figure 1-2
System Board Jumper and C
onnector Locations
The blackened pin
of a jumper or connector
represents pin 1.
1-
4
User’s Gu
ide
17
19
