Table 1-2 S1 Settings for CPU Selection
CPU Freq.
(MHz)
Host Bus
Freq. (MHz)
Switch Settings
SW1 SW2 SW3 SW4
Clock
Ratio
Intel P54C/P55C, AMD K5 /K6
233 66 Off Off On Off 7/2
200 66 On Off On Off 3
180 60 On Off Off On 3
166 66 On On On Off 5/2
150 60 On On Off On 5/2
133 66 Off On On Off 2
120 60 Off On Off On 2
100 66 Off Off On Off 3/2
90 60 Off Off Off On 3/2
75 50 Off Off On On 3/2
Reserved -- -- -- -- -- --
Cyrix M1/IBM 6x86
P166+ 66 Off On On Off 2
P150+ 60 Off On Off On 2
P120+ 50 Off On On On 2
Note that the 233 MHz CPU frequency applies to
the Intel Pentium CPU only.
