Technical data: Dimensions and
weights
Tractor type 1038 1042 1046 1050
Max. rear bar axle flange width (3000
mm).
2975 mm with duo hub
Standard track front 2100 mm
Standard track rear 1970 mm to 2100 mm
Front bolt pitch-circle diameter 425 mm
Rear bolt pitch-circle diameter 425 mm
Overall transmission ratio 0.7837
Rear axle ratio 27.271
Front axle ratio 17.6
Noise values
Standing noise (external) 81 dB(A)
Ear height noise (internal, cab closed) 71 dB(A)
Ear height noise (internal, cab open) 73 dB(A)
Whole body vibration intensity on
operator's seat according to 78/764/
EEC
<1.25 m/s²
Tightening torques
Wheel nuts (front) 580 Nm
Rear wheel nuts Black: 620 Nm, dacrometized: 580 Nm
4.1.2 Technical data: Gearbox
Vario: continuously variable transmisssion
Model
ML 400
Speed (forwards)
40 km/h/50 km/h/60 km/h
Speed (backwards)
33 km/h
Acceleration rate I (if the
joystick is touched once at
rated engine speed)
0.02 km/h ... 0.5 km/h (adjustable)
Acceleration rate II (if the
joystick is touched once at
rated engine speed)
0.5 km/h
Acceleration rate III (if the
joystick is touched once at
rated engine speed)
1.0 km/h
4. TECHNICAL DATA
242 Maintenance
530.020.020.011 Rev.A
