2.9.3 Pour in the transmission oil
Pour in the transmission oil
Procedure
1.
Remove the dipstick (A) and pour oil in
through the filler neck.
2.
Start the engine and let it run for at least five
minutes so that the brake housing is filled.
3.
Visual inspection for leaks.
4.
Check the oil level.
Fig. 43
2.9.4 Drain final drive oil
Preliminary conditions
• Only carry out oil change when the transmission oil is warm.
Drain final drive oil
NOTE:
Collect used oil; do not let it seep into the ground.
Dispose of drained oil according to the appropriate regulations.
Procedure
1.
Place an oil drip pan underneath the axle.
2.
Loosen the oil drain plugs (A) and (B) on both
sides of the axle housing and allow the oil to
drain completely.
3.
Clean the oil drain plugs (A) and (B), screw in
and tighten.
Fig. 44
2.9.5 Fill the final drives with oil
Fill the final drives with oil
2. Service and maintenance
46 Maintenance
530.020.020.011 Rev.A
