Procedure
Fill the required oil through the filler hole (A)
on the left and right axle housing, up to
approx. 61 mm below the filler hole.
Fig. 45
2.9.6 Change the pressure and suction filters
To Change the pressure filter:
Procedure
1.
Unscrew the filter canister (A).
2.
Pull out the filter element from the canister.
3.
Replace the filter element; do not wash out.
NOTE:
Used oil filters are hazardous waste!
4.
Lightly oil the sealing rings.
5.
Fit filter canister (A) and tighten with screw
(tightening torque: 40 Nm).
Fig. 46
2.9.6.1 Replacing the suction filter:
Procedure
1.
Drain transmission oil.
2.
Remove cover (A) and pull out suction filter.
3.
Change the replaceable cartridge.
NOTE:
Used oil filters are hazardous waste!
4.
Screw on cover (A).
5.
Replenish transmission oil.
Fig. 47
2. Service and maintenance
Maintenance 47
530.020.020.011 Rev.A
