3-5
Specifications and Characteristics
Characteristics
Horizontal
Range 2 ns/div to 50 s/div
Timebase Accuracy ±100 ppm over any time interval ≥ 1 ms
Modes Main, Delayed, Roll, XY
Trigger System
Sources Channel 1, channel 2, ac line, ext, and ext/5
Sweep Auto and Normal
Holdoff Time 100 ns to 1.5 s
Selections
Edge Trigger on a rising or falling edge of any source
Pulse Width Trigger when a positive-going or negative-going pulse is less than, greater than, or equal
to a specified value on any of the source channels
Range: 20 ns to 10 s
Video Trigger on any analog channel for NTSC, PAL, or SECAM broadcast standards on either
positive or negative composite video signals. Modes supported include Even Field, Odd
Field, all lines, or any line within a field.
Maximum Input CAT II 300 Vrms
Trigger Level Range
Internal ±12 divisions from center screen
EXT ± 2.4 V
EXT/5 ± 12 V
Sensitivity
DC CH1, CH2: 1 div (DC to 10 MHz)
1.5 div (10 MHz to full bandwidth)
EXT: 100 mV (DC to 10 MHz), 200 mV (10 MHz to full bandwidth)
EXT/5: 500 mV (DC to 10 MHz), 1 V (10 MHz to full bandwidth)
AC Same as DC at 50 Hz and above
LF Reject Same as DC limits for frequencies above 100 kHz. Waveforms below 8 kHz are attenuated
HF Reject Same as DC limits for frequencies from DC to 10 kHz. Frequencies above 150 kHz are
attenuated
Display System
Display 5.7-inch (145 mm) diagonal liquid crystal display
Resolution 240 vertical by 320 horizontal pixels
Display Brightness Adjustable
