4.1 产品描述
操作说明
Operator Instruction
Product Description
本说明书介绍了沭河 SH90 系列包括 SH800/SH804、SH850/SH854、SH900/SH904、SH950/SH954、
SH1000/SH1004 十种型号的轮式拖拉机的使用、技术保养、调整、故障和排除方法等。
This Operation Instruction introduces application, technical maintenance, adjustment, failure and its
elimination of SHUHE SH series, including ten models of wheeled
tractors.i.e.SH800/SH804/SH850/SH854/SH900/SH904/SH950/SH954/SH1000/SH1004
沭河 SH90 系列轮式拖拉机是一种多用途的中型农用轮式拖拉机。该机具有结构紧凑、操纵方便、转向
灵活、提升力大和维修保养方便等特点。
SH90 series wheeled tractor is a kind of multifunctional large wheeled tractor used for farm. The farm machine
tool has compact in structure, easy control, flexible steering, high lifting capacity and maintainability.
4.2 拖拉机操纵机构及仪表
Operating mechanism and instrument of tractor
4.2.1 拖拉机操纵机构
0peration mechanism for the tractor
发动机冷却液
温度
Engine coolant
temperature
燃油油量
Fuel volume
驻车制动
Parking brake
差速锁
differential lock
危险指示灯
Hazard
indicator light
警报灯
Warning light
