English
Technical data
8 TECHNICAL DATA
8.1 Pressure drops in the evaporator
PRESSURE DROPS IN THE EVAPORATOR
CLS 182 CLS 202 CLS 242 CLS 302 CLS 352
K 52.3 41.5 29.4 21.0 12.5
Min. water flow rate l/s 1.4 1.8 2.2 2.5 3.1
Nominal flow rate l/s 1.9 2,6 3,1 3.5 4.3
Max. water flow rate l/s 3.2 4.3 5.2 5.9 7.2
Min. pressure drops kPa 10.1 14.1 14.4 13.5 11.8
Nominal pressure drops kPa 19.9 27.7 28.3 26.4 23.2
Max. pressure drops kPa 55.3 77.0 78.6 73.3 64.4
PRESSURE DROPS IN THE EVAPORATOR
CLS 402 CLS 502 CLS 552 CLS 602
K 10.6 10.6 10.6 10.6
Min. water flow rate l/s 3.6 4.1 4.6 5.1
Nominal flow rate l/s 5.0 5.8 6.5 7.1
Max. water flow rate l/s 8.4 9.7 10.8 11.9
Min. pressure drops kPa 13.7 18.2 22.7 27.6
Nominal pressure drops kPa 26.9 35.7 44.4 54.1
Max. pressure drops kPa 74.6 99.5 123.5 150.4
PRESSURE DROPS IN THE EVAPORATOR
CLH 182 CLH 202 CLH 242 CLH 302 CLH 352
K 52.3 41.5 29.4 21.0 12.5
Min. water flow rate l/s 1.4 1.9 2.3 2.7 3.0
Nominal flow rate l/s 1.9 2,6 3,2 3.8 4.2
Max. water flow rate l/s 3.2 4.4 5.4 6.3 7.0
Min. pressure drops kPa 10.1 14.5 15.5 15.1 11.3
Nominal pressure drops kPa 19.9 28.4 30.4 29.5 22.1
Max. pressure drops kPa 55.3 78.9 84.5 82.1 61.5
PRESSURE DROPS IN THE EVAPORATOR
CLH 402 CLH 502 CLH 552 CLH 602
K 10.6 10.6 10.6 10.6
Min. water flow rate l/s 3.4 3.8 4.1 4.5
Nominal flow rate l/s 4.7 5.3 5.8 6.3
Max. water flow rate l/s 7.9 8.8 9.6 10.5
Min. pressure drops kPa 12.0 15.1 18.1 21.3
Nominal pressure drops kPa 23.6 29.5 35.4 41.8
Max. pressure drops kPa 65.6 82.0 98.4 116.2
qP = K · Q
2
/ 10
