Replacing the display bezel
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your computer.
For more safety best practices, see the Regulatory Compliance home
page at
www.dell.com/regulatory_compliance.
Procedure
1 Place the display assembly on a clean and flat surface.
2 Connect the tron-light cables to the logo board.
3 Connect the logo-board cable to the logo board.
4 Slide the alien head cable into the logo board and close the latch to secure
the cable.
5 Carefully turn the display bezel over.
6 Align the display bezel with the display back-cover and gently snap the
display bezel into place.
Post-requisites
1 Replace the display assembly.
2 Follow the procedure from step 2 to step 16 in “Replacing the system board”.
3 Replace the memory modules.
4 Replace the battery.
5 Replace the computer base.
6 Replace the rear-I/O cover.
7 Replace the solid-state drive.
8 Follow the procedure from step 4 to step 6 in "Replacing the hard drive".
9 Replace the wireless card.
10 Replace the base cover.
91
