Steps
1. Adhere the battery cable to the battery.
2. Connect the battery cable to the latch on the battery.
3. Adhere the tape back on the battery.
4. Turn the battery over.
Next steps
1. Install the
battery.
2. Install the base cover.
3. Follow the procedure in
After working inside your computer.
Solid-state drive
Removing the 2230 solid-state drive in slot three and four
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
About this task
The following image(s) indicate the location of the 2230 solid-state drive in slot three and four and provides a visual representation
of the removal procedure.
NOTE: Computers shipped with NVIDIA GeForce RTX 4080/4090 graphics card have two M.2 2230 and two M.2 2280
solid-state drive slots, whereas computers shipped with NVIDIA GeForce RTX 4050/4060/4070 graphics card have only two
M.2 2280 solid-state drive slots.
