ALLEN & HEATH XONE:43C User Manual

Allen & Heath 26 XONE:43C User Guide
Dimensions and Weights
The console is fitted with rubber feet for desktop operation.
Width Height Depth Weight
Mixer 320 mm 110mm 370mm 5.2 kg
SPECIFICATIONS
Nom / max output levels Main Mix +4dBu +27dBu
Booth 0dBu +22dBu
X:FX Send 0dBu +20dBu
Record Out 0dBu +20dBu
Internal headroom Channels +20dB
Frequency response +/-0.5dB 20Hz - 20kHz
Distortion < 0.05% THD+noise @1kHz
Crosstalk < -83dB inter-channel
Residual noise Mix 1 -89dBu
Booth -93dBu
X:FX -77dBu
Rec -92dBu
Mix noise Mix 1 -82dBu
Booth -84dBu
X:FX -77dBu
Rec -87dBu
Channel meters Peak reading 9 LED -20dB to +10dB
Main meters Peak reading 9 LED -20dB to +10dB
Mic EQ 2-Band +/-12dB
Channel EQ 3-Band +6dB / total kill
Channel fader 45mm stereo VCA, < -85dB shutoff
Crossfader 45mm stereo VCA - replaceable
Filters Stereo VCF, analogue
Digital Architecture Specification
Analogue/Digital conversion 24 bit
Analogue/Digital Line-up +14dBu = 0dBFS
USB soundcard sampling frequency range 44.1kHz to 96kHz
Consumption 30W max

ALLEN & HEATH XONE:43C Specifications

General

Sample rate	96 kHz
Channels quantity	16 channels
Digital sound processing	24 bit
Line Signal-to-Noise Ratio (SNR)	20 dB
Total Harmonic Distortion (THD)	0.05 %
Microphone in	Yes
Headphone connectivity	3.5 mm
Product color	Black
Video capability	No
Power consumption (typical)	30 W
Equalizer bands quantity	3

Weight and Dimensions

Depth	370 mm
Width	320 mm
Height	110 mm
Weight	5200 g
