Allen-Bradley PicoTM Controller 1760 User Manual

Publication 1760-GR001C-EN-P - April 2005
Drawing a Circuit with Pico 2-13
Function Relay Types
Timing Relay
Circuit Diagram
Symbol
Function Relay Type
Timing relay with on-delay, with and without random switching
Timing relay with off-delay, with and without random switching
Timing relay, single pulse
Timing relay, flashing
Counter relay, up/down counter
Time switch, weekday/time (only in Pico models with clock)
Analog comparator relay (only in Pico models with 24V dc)
X?X
Trigger
Reset
on
on
on
ttt
Timing Relay with on delay, with and
without random switching
Timer Output
