Allen-Bradley PowerFlex 520 Series User Manual

140 Rockwell Automation Publication 520-UM001G-EN-E - September 2014
Chapter 3 Programming and Parameters
Parameter Cross Reference by Name
Parameter Name No. Parameter Name No. Parameter Name No.
10V Bipolar Enbl
(1)
093 Current Limit 2
(1)
485 Drv 4 Reference 722
2-Wire Mode 064 DB Resistor Sel 437 Drv Ambient Sel 554
Accel Time 1 041 DB Threshold 438 DSI Errors 731
Accel Time 2 442 DC Brake Level 435 DSI I/O Act 686
Accel Time 3 444 DC Brake Time 434 DSI I/O Cfg 175
Accel Time 4 446 DC Brk Time@Strt 436 Elapsed kWh 021
Accum CO2 Sav 026 DC Bus Ripple 380 Elapsed MWh 022
Accum Cost Sav 025 DC Bus Voltage 005 Elapsed Run Time 019
Accum kWh Sav 024 Decel Time 1 042 Elapsed Time-hr 362
Analog In 0-10V 360 Decel Time 2 443 Elapsed Time-min 363
Analog In 4-20mA 361 Decel Time 3 445 EM Brk Off Delay 086
Analog In Filter 099 Decel Time 4 447 EM Brk On Delay 087
Analog Out High
(1)
089 Dig In Status 014 EN Addr Sel
(1)
128
Analog Out Sel
(1)
088 DigIn TermBlk 02 062 EN Addr Src
(1)
684
Anlg In 0-10V Hi 092 DigIn TermBlk 03 063 EN Comm Flt Actn
(1)
143
Anlg In 0-10V Lo 091 DigIn TermBlk 05 065 EN Data In 1
(1)
153
Anlg In mA Loss 097 DigIn TermBlk 06 066 EN Data In 2
(1)
154
Anlg In V Loss 094 DigIn TermBlk 07
(1)
067 EN Data In 3
(1)
155
Anlg In4-20mA Hi 096 DigIn TermBlk 08
(1)
068 EN Data In 4
(1)
156
Anlg In4-20mA Lo 095 Drive OL Mode 495 EN Data Out 1
(1)
157
Anlg Loss Delay 098 Drive Status 006 EN Data Out 2
(1)
158
Anlg Out Setpt
(1)
090 Drive Temp 027 EN Data Out 3
(1)
159
Auto Rstrt Delay 542 Drive Type 367 EN Data Out 4
(1)
160
Auto Rstrt Tries 541 Droop Hertz@ FLA
(1)
441 EN Flt Cfg DL 1
(1)
147
Autotune 040 Drv 0 Feedback 708 EN Flt Cfg DL 2
(1)
148
Average kWh Cost 052 Drv 0 Logic Cmd 705 EN Flt Cfg DL 3
(1)
149
Average Power 020 Drv 0 Logic Sts 707 EN Flt Cfg DL 4
(1)
150
Boost Select 530 Drv 0 Reference 706 EN Flt Cfg Logic
(1)
145
Break Frequency 533 Drv 1 Addr 171 EN Flt Cfg Ref
(1)
146
Break Voltage 532 Drv 1 Feedback 712 EN Gateway Act 1
(1)
701
Bus Reg Enable 550 Drv 1 Logic Cmd 709 EN Gateway Act 2
(1)
702
Cmd Stat Select
(1)
122 Drv 1 Logic Sts 711 EN Gateway Act 3
(1)
703
Com Sts-Emb Enet
(1)
683 Drv 1 Reference 710 EN Gateway Act 4
(1)
704
Comm Loss Action 125 Drv 2 Addr 172 EN Gateway Cfg 1
(1)
137
Comm Loss Time 126 Drv 2 Feedback 716 EN Gateway Cfg 2
(1)
138
Comm Sts - DSI 681 Drv 2 Logic Cmd 713 EN Gateway Cfg 3
(1)
139
Comm Sts - Opt 682 Drv 2 Logic Sts 715 EN Gateway Cfg 4
(1)
140
Comm Write Mode 121 Drv 2 Reference 714 EN Idle Flt Actn
(1)
144
Commanded Freq 002 Drv 3 Addr 173 EN IP Addr Act 1
(1)
693
Compensation 547 Drv 3 Feedback 720 EN IP Addr Act 2
(1)
694
Contrl In Status 013 Drv 3 Logic Cmd 717 EN IP Addr Act 3
(1)
695
Control Source 012 Drv 3 Logic Sts 719 EN IP Addr Act 4
(1)
696
Control SW Ver 029 Drv 3 Reference 718 EN IP Addr Cfg 1
(1)
129
Control Temp 028 Drv 4 Addr 174 EN IP Addr Cfg 2
(1)
130
Counter Status 364 Drv 4 Feedback 724 EN IP Addr Cfg 3
(1)
131
Counts Per Unit
(1)
559 Drv 4 Logic Cmd 721 EN IP Addr Cfg 4
(1)
132
Current Limit 1 484 Drv 4 Logic Sts 723 EN Missed IO Pkt
(1)
730
(1) Parameter is specific to PowerFlex 525 drives only.
