Allen-Bradley PowerFlex 520 Series User Manual

Rockwell Automation Publication 520-UM001G-EN-E - September 2014 67
Programming and Parameters Chapter 3
Logic
(1)
Stp Logic 0 L180
Stp Logic 1 L181
Stp Logic 2 L182
Stp Logic 3 L183
Stp Logic 4 L184
Stp Logic 5 L185
Stp Logic 6 L186
Stp Logic 7 L187
Stp Logic Time 0 L190
Stp Logic Time 1 L191
Stp Logic Time 2 L192
Stp Logic Time 3 L193
Stp Logic Time 4 L194
Stp Logic Time 5 L195
Stp Logic Time 6 L196
Stp Logic Time 7 L197
Step Units 0 L200
Step Units 1 L202
Step Units 2 L204
Step Units 3 L206
Step Units 4 L208
Step Units 5 L210
Step Units 6 L212
Step Units 7 L214
Advanced Display
Analog In 0-10V d360
Analog In 4-20mA d361
Elapsed Time-hr d362
Elapsed Time-min d363
Counter Status d364
Timer Status d365
Drive Type d367
Testpoint Data d368
Motor OL Level d369
Slip Hz Meter d375
Speed Feedback d376
Encoder Speed
(1)
d378
DC Bus Ripple d380
Output Powr Fctr d381
Torque Current d382
PID1 Fdbk Displ d383
PID1 Setpnt Disp d384
PID2 Fdbk Displ d385
PID2 Setpnt Disp d386
Position Status d387
Units Traveled H
(1)
d388
Units Traveled L
(1)
d389
Fiber Status d390
Stp Logic Status
(1)
d391
RdyBit Mode Act
(1)
d392
Advanced Program
Preset Freq 0 A410
Preset Freq 1 A411
Preset Freq 2 A412
Preset Freq 3 A413
Preset Freq 4 A414
Preset Freq 5 A415
Preset Freq 6 A416
Preset Freq 7 A417
Preset Freq 8
(1)
A418
Preset Freq 9
(1)
A419
Preset Freq 10
(1)
A420
Preset Freq 11
(1)
A421
Preset Freq 12
(1)
A422
Preset Freq 13
(1)
A423
Preset Freq 14
(1)
A424
Preset Freq 15
(1)
A425
Keypad Freq A426
MOP Freq A427
MOP Reset Sel A428
MOP Preload A429
MOP Time A430
Jog Frequency A431
Jog Accel/Decel A432
Purge Frequency A433
DC Brake Time A434
DC Brake Level A435
DC Brk Time@Strt A436
DB Resistor Sel A437
DB Threshold A438
S Curve % A439
PWM Frequency A440
Droop Hertz@ FLA
(1)
A441
Accel Time 2 A442
Decel Time 2 A443
Accel Time 3 A444
Decel Time 3 A445
Accel Time 4 A446
Decel Time 4 A447
Skip Frequency 1 A448
Skip Freq Band 1 A449
Skip Frequency 2 A450
Skip Freq Band 2 A451
Skip Frequency 3
(1)
A452
Skip Freq Band 3
(1)
A453
Skip Frequency 4
(1)
A454
Skip Freq Band 4
(1)
A455
PID 1 Trim Hi A456
PID 1 Trim Lo A457
PID 1 Trim Sel A458
PID 1 Ref Sel A459
PID 1 Fdback Sel A460
PID 1 Prop Gain A461
PID 1 Integ Time A462
PID 1 Diff Rate A463
PID 1 Setpoint A464
PID 1 Deadband A465
PID 1 Preload A466
PID 1 Invert Err A467
PID 2 Trim Hi
(1)
A468
PID 2 Trim Lo
(1)
A469
PID 2 Trim Sel
(1)
A470
PID 2 Ref Sel
(1)
A471
PID 2 Fdback Sel
(1)
A472
PID 2 Prop Gain
(1)
A473
PID 2 Integ Time
(1)
A474
PID 2 Diff Rate
(1)
A475
PID 2 Setpoint
(1)
A476
PID 2 Deadband
(1)
A477
PID 2 Preload
(1)
A478
PID 2 Invert Err
(1)
A479
Process Disp Lo A481
Process Disp Hi A482
Testpoint Sel A483
Current Limit 1 A484
Current Limit 2
(1)
A485
Shear Pin1 Level A486
Shear Pin 1 Time A487
Shear Pin2 Level
(1)
A488
Shear Pin 2 Time
(1)
A489
Load Loss Level
(1)
A490
Load Loss Time
(1)
A491
Stall Fault Time A492
Motor OL Select A493
Motor OL Ret A494
Drive OL Mode A495
IR Voltage Drop A496
Flux Current Ref A497
Motor Rr
(1)
A498
Motor Lm
(1)
A499
Motor Lx
(1)
A500
Speed Reg Sel A509
Freq 1 A510
Freq 1 BW A511
Freq 2 A512
Freq 2 BW A513
Freq 3 A514
Freq 3 BW A515
Freq 1 Kp A521
Freq 1 Ki A522
Freq 2 Kp A523
Freq 2 Ki A524
Freq 3 Kp A525
Freq 3 Ki A526
Boost Select A530
Start Boost A531
Break Voltage A532
Break Frequency A533
Maximum Voltage A534
Motor Fdbk Type
(1)
A535
Encoder PPR
(1)
A536
Pulse In Scale A537
Ki Speed Loop
(1)
A538
Kp Speed Loop
(1)
A539
Var PWM Disable A540
Auto Rstrt Tries A541
Auto Rstrt Delay A542
Start At PowerUp A543
Reverse Disable A544
Flying Start En A545
FlyStrt CurLimit A546
Compensation A547
Power Loss Mode A548
Half Bus Enable A549
Bus Reg Enable A550
Fault Clear A551
Program Lock A552
Program Lock Mod A553
Drv Ambient Sel A554
Reset Meters A555
Text Scroll A556
Out Phas Loss En A557
Positioning Mode
(1)
A558
Counts Per Unit
(1)
A559
Enh Control Word
(1)
A560
Home Save
(1)
A561
Find Home Freq
(1)
A562
Find Home Dir
(1)
A563
Encoder Pos Tol
(1)
A564
Pos Reg Filter
(1)
A565
Pos Reg Gain
(1)
A566
Max Traverse A567
Traverse Inc A568
Traverse Dec A569
P Jump A570
Sync Time A571
Speed Ratio A572
Mtr Options Cfg A573
RdyBit Mode Cfg
(1)
A574
Network
This group contains parameters for the network option card that is installed.
See the network option card’s user manual for more information on the available parameters.
Modified
This group contains parameters that have their values changed from the factory default.
When a parameter has its default value changed, it is automatically added to this group. When a parameter has its value changed back to the
factory default, it is automatically removed from this group.
(1) Parameter is specific to PowerFlex 525 drives only.
