14 Rockwell Automation Publication 520-QS001A-EN-E - March 2014
PowerFlex 520-Series Adjustable Frequency AC Drive
PowerFlex 525 Control I/O Terminal Designations
No. Signal Default Description Parameter
R1 Relay 1 N.O. Fault Normally open contact for output relay. t076
R2 Relay 1 Common Fault Common for output relay.
R5 Relay 2 Common Motor Running Common for output relay. t081
R6 Relay 2 N.C. Motor Running Normally closed contact for output relay.
01 Stop Coast Three wire stop. However, it functions as a stop under all input modes and cannot be disabled. P045
02 DigIn TermBlk 02/
Start/Run FWD
Run FWD Used to initiate motion and also can be used as a programmable digital input. It can be programmed with t062 [DigIn
TermBlk 02] as three wire (Start/Dir with Stop) or two wire (Run FWD/Run REV) control. Current consumption is 6 mA.
P045, P046,
P048, P050,
A544, t062
03 DigIn TermBlk 03/
Dir/Run REV
Run REV Used to initiate motion and also can be used as a programmable digital input. It can be programmed with t062 [DigIn
TermBlk 02] as three wire (Start/Dir with Stop) or two wire (Run FWD/Run REV) control. Current consumption is 6 mA.
t063
04 Digital Common – Return for digital I/O. Electrically isolated (along with the digital I/O) from the rest of the drive. –
05 DigIn TermBlk 05 –Preset Freq Program with t065 [DigIn TermBlk 05]. Current consumption is 6 mA. t065
06 DigIn TermBlk 06 –Preset Freq Program with t066 [DigIn TermBlk 06]. Current consumption is 6 mA. t066
07 DigIn TermBlk 07/
Pulse In
Start Source 2
+ Speed
Reference2
Program with t067 [DigIn TermBlk 07]. Also functions as a Pulse Train input for reference or speed feedback. The
maximum frequency is 100 kHz. Current consumption is 6 mA.
t067
08 DigIn TermBlk 08 Jog Forward Program with t068 [DigIn TermBlk 08]. Current consumption is 6 mA. t068
C1 C1 – This terminal is tied to the RJ-45 port shield. Tie this terminal to a clean ground in order to improve noise immunity
when using external communication peripherals.
–
C2 C2 – This is the signal common for the communication signals. –
S1 Safety 1 – Safety input 1. Current consumption is 6 mA. –
S2 Safety 2 – Safety input 2. Current consumption is 6 mA. –
S+ Safety +24V – +24V supply for safety circuit. Internally tied to the +24V DC source (Pin 11). –
11 +24V DC – Referenced to Digital Common. Drive supplied power for digital inputs. Maximum output current is 100 mA. –
12 +10V DC – Referenced to Analog Common. Drive supplied power for 0...10V external potentiometer.
Maximum output current is 15 mA.
P047, P049
13 ±10V In Not Active For external 0-10V (unipolar) or ±10V (bipolar) input supply or potentiometer wiper.
Input impedance: Voltage source = 100 kW
Allowable potentiometer resistance range = 1...10 kW
P047, P049,
t062, t063,
t065, t066,
t093, A459,
A471
14 Analog Common – Return for the analog I/O. Electrically isolated (along with the analog I/O) from the rest of the drive. –
15 4-20mA In Not Active For external 4-20 mA input supply.
Input impedance = 250 W
P047, P049,
t062, t063,
t065, t066,
A459, A471
16 Analog Output OutFreq 0-10 The default analog output is 0-10V. To convert a current value, change the Analog Output jumper to 0-20 mA. Program
with t088 [Analog Out Sel]. Maximum analog value can be scaled with t089 [Analog Out High].
Maximum Load: 4-20 mA = 525 W (10.5V)
0-10V = 1 kW (10 mA)
t088, t089
17 Opto Output 1 Motor Running Program with t069 [Opto Out1 Sel].
Each Opto-Output is rated 30V DC 50 mA (Non-inductive).
t069, t070,
t075
18 Opto Output 2 At Frequency Program with t072 [Opto Out1 Sel].
Each Opto-Output is rated 30V DC 50 mA (Non-inductive).
t072, t073,
t075
19 Opto Common – The emitters of the Optocoupler Outputs (1 and 2) are tied together at Optocoupler Common. Electrically isolated from
the rest of the drive.
–
