Allen-Bradley PowerFlex 525 Quick Start

6 Rockwell Automation Publication 520-QS001A-EN-E - March 2014
PowerFlex 520-Series Adjustable Frequency AC Drive
Fuses and Circuit Breakers
Catalog No.
(1)
Output Ratings Input Ratings Branch Circuit Protection
Min. Enclosure Volume (in.
3
)
IP 20 Open Type Watts Loss
PowerFlex
523
PowerFlex
525
Normal Duty Heavy Duty
Amps
Voltage
Range kVA
Max
Amps
(2)
Fuse
Ratings
Min/Max Contactors
140M Motor
Protectors
(3) (4) (5)
HP kW HP kW
100...120V AC (-15%, +10%) – 1-Phase Input, 0...230V 3-Phase Output
25A-V1P6N104 – 0.25 0.2 0.25 0.2 1.6 85...132 0.8 6.4 10/16 100-C09 140M-C2E-B63 – 20.0
25A-V2P5N104 25B-V2P5N104 0.5 0.4 0.5 0.4 2.5 85...132 1.3 9.6 16/20 100-C12 140M-C2E-C10 – 27.0
25A-V4P8N104 25B-V4P8N104 1.0 0.75 1.0 0.75 4.8 85...132 2.5 19.2 25/40 100-C23 140M-D8E-C20 – 53.0
25A-V6P0N104 25B-V6P0N104 1.5 1.1 1.5 1.1 6.0 85...132 3.2 24.0 32/50 100-C23 140M-F8E-C25 – 67.0
200...240V AC (-15%, +10%) – 1-Phase Input, 0...230V 3-Phase Output
25A-A1P6N104 – 0.25 0.2 0.25 0.2 1.6 170...264 1.4 5.3 6/10 100-C09 140M-C2E-B63 – 20.0
25A-A2P5N104 25B-A2P5N104 0.5 0.4 0.5 0.4 2.5 170...264 1.7 6.5 10/16 100-C09 140M-C2E-C10 – 29.0
25A-A4P8N104 25B-A4P8N104 1.0 0.75 1.0 0.75 4.8 170...264 2.8 10.7 16/25 100-C12 140M-C2E-C16 – 50.0
25A-A8P0N104 25B-A8P0N104 2.0 1.5 2.0 1.5 8.0 170...264 4.8 18.0 25/40 100-C23 140M-F8E-C25 – 81.0
25A-A011N104 25B-A011N104 3.0 2.2 3.0 2.2 11.0 170...264 6.0 22.9 32/50 100-C37 140M-F8E-C25 – 111.0
200...240V AC (-15%, +10%) – 1-Phase Input with EMC Filter, 0...230V 3-Phase Output
25A-A1P6N114 – 0.25 0.2 0.25 0.2 1.6 170...264 1.4 5.3 6/10 100-C09 140M-C2E-B63 – 20.0
25A-A2P5N114 25B-A2P5N114 0.5 0.4 0.5 0.4 2.5 170...264 1.7 6.5 10/16 100-C09 140M-C2E-C10 – 29.0
25A-A4P8N114 25B-A4P8N114 1.0 0.75 1.0 0.75 4.8 170...264 2.8 10.7 16/25 100-C12 140M-C2E-C16 – 53.0
25A-A8P0N114 25B-A8P0N114 2.0 1.5 2.0 1.5 8.0 170...264 4.8 18.0 25/40 100-C23 140M-F8E-C25 – 84.0
25A-A011N114 25B-A011N114 3.0 2.2 3.0 2.2 11.0 170...264 6.0 22.9 32/50 100-C37 140M-F8E-C25 – 116.0
200...240V AC (-15%, +10%) – 3-Phase Input, 0...230V 3-Phase Output
25A-B1P6N104 – 0.25 0.2 0.25 0.2 1.6 170...264 0.9 1.9 3/6 100-C09 140M-C2E-B25 – 20.0
25A-B2P5N104 25B-B2P5N104 0.5 0.4 0.5 0.4 2.5 170...264 1.2 2.7 6/6 100-C09 140M-C2E-B40 – 29.0
25A-B5P0N104 25B-B5P0N104 1.0 0.75 1.0 0.75 5.0 170...264 2.7 5.8 10/16 100-C09 140M-C2E-B63 – 50.0
25A-B8P0N104 25B-B8P0N104 2.0 1.5 2.0 1.5 8.0 170...264 4.3 9.5 16/20 100-C12 140M-C2E-C10 – 79.0
25A-B011N104 25B-B011N104 3.0 2.2 3.0 2.2 11.0 170...264 6.3 13.8 20/32 100-C23 140M-C2E-C16 – 107.0
25A-B017N104 25B-B017N104 5.0 4.0 5.0 4.0 17.5 170...264 9.6 21.1 32/45 100-C23 140M-F8E-C25 – 148.0
25A-B024N104 25B-B024N104 7.5 5.5 7.5 5.5 24.0 170...264 12.2 26.6 35/63 100-C37 140M-F8E-C32 – 259.0
25A-B032N104 25B-B032N104 10.0 7.5 10.0 7.5 32.2 170...264 15.9 34.8 45/70 100-C43 140M-F8E-C45 – 323.0
25A-B048N104 25B-B048N104 15.0 11.0 10.0 7.5 48.3 170...264 20.1 44.0 63/90 100-C60 140M-F8E-C45 1416.0
(7)
584.0
25A-B062N104 25B-B062N104 20.0 15.0 15.0 11.0 62.1 170...264 25.6 56.0 70/125 100-C72 – – 708.0
380...480V AC (-15%, +10%) – 3-Phase Input, 0...460V 3-Phase Output
25A-D1P4N104 25B-D1P4N104 0.5 0.4 0.5 0.4 1.4 323...528 1.7 1.9 3/6 100-C09 140M-C2E-B25 – 27.0
25A-D2P3N104 25B-D2P3N104 1.0 0.75 1.0 0.75 2.3 323...528 2.9 3.2 6/10 100-C09 140M-C2E-B40 – 37.0
25A-D4P0N104 25B-D4P0N104 2.0 1.5 2.0 1.5 4.0 323...528 5.2 5.7 10/16 100-C09 140M-C2E-B63 – 80.0
25A-D6P0N104 25B-D6P0N104 3.0 2.2 3.0 2.2 6.0 323...528 6.9 7.5 10/16 100-C09 140M-C2E-C10 – 86.0
25A-D010N104 25B-D010N104 5.0 4.0 5.0 4.0 10.5 323...528 12.6 13.8 20/32 100-C23 140M-C2E-C16 – 129.0
25A-D013N104 25B-D010N104 7.5 5.5 7.5 5.5 13.0 323...528 14.1 15.4 20/35 100-C23 140M-D8E-C20 – 170.0
25A-D017N104 25B-D017N104 10.0 7.5 10.0 7.5 17.0 323...528 16.8 18.4 25/40 100-C23 140M-D8E-C20 – 221.0
25A-D024N104 25B-D024N104 10.0 7.5 10.0 7.5 17.0 323...528 24.1 26.4 35/63 100-C37 140M-F8E-C32 656.7
(7)
221.0
25A-D030N104 25B-D030N104 20.0 15.0 15.0 11.0 30.0 323...528 30.2 33.0 45/70 100-C43 140M-F8E-C45 656.7
(7)
387.0
380...480V AC (-15%, +10%) – 3-Phase Input with EMC Filter, 0...460V 3-Phase Output
25A-D1P4N114 25B-D1P4N114 0.5 0.4 0.5 0.4 1.4 323...528 1.7 1.9 3/6 100-C09 140M-C2E-B25 – 27.0
25A-D2P3N114 25B-D2P3N114 1.0 0.75 1.0 0.75 2.3 323...528 2.9 3.2 6/10 100-C09 140M-C2E-B40 – 37.0
25A-D4P0N114 25B-D4P0N114 2.0 1.5 2.0 1.5 4.0 323...528 5.2 5.7 10/16 100-C09 140M-C2E-B63 – 81.0
25A-D6P0N114 25B-D6P0N114 3.0 2.2 3.0 2.2 6.0 323...528 6.9 7.5 10/16 100-C09 140M-C2E-C10 – 88.0
25A-D010N114 25B-D010N114 5.0 4.0 5.0 4.0 10.5 323...528 12.6 13.8 20/32 100-C23 140M-C2E-C16 – 133.0
