Alpine CDE-W235BT Quick Reference Guide

22-EN
You can set whether this unit can be recognized or not from a
BLUETOOTH compatible device. Normally set this to VISI M ON.
 Setting item: VISIBLE M
Setting contents:
VISI M OFF / VISI M ON (Initial setting)
VISI M OFF:
Disable recognition of this unit from the BLUETOOTH compatible
device.
VISI M ON:
Enable recognition of this unit from the BLUETOOTH compatible
device.
The BLUETOOTH device is used when a connectable BLUETOOTH
compatible device is searched and connected to this unit, or when a new
BLUETOOTH compatible device is registered.
 Setting item: SEARCH DEV
1 When SEARCH DEV is selected, and “SEARCHING” is
displayed, the search gets started.
Note
• The “SEARCHING” operation can be stopped by pressing .
2 Turn the Rotary encoder to select the name of the device
to be connected from the Device Search list and then
press ENTER.
3 If this unit is successfully connected to a BLUETOOTH
compatible device, “CONNECTED” is displayed, and then
the unit returns to normal mode.
Depending on the mobile phone, it may be necessary to input a
passcode. In this case, “CODE 0000” is displayed. Input the
passcode “0000” in the BLUETOOTH compatible device to make
the pairing. After the pairing is completed, the unit will
automatically connect to the BLUETOOTH compatible device. If
you input the wrong passcode or the communication fails,
“FAILED” is displayed.
You can flexibly customize the sound of call to fit your own preferences.
 Setting item: CALL SOUND
 Further setting items: VOL LV ADJ / AUTO SET
Adjusting the volume (VOL LV ADJ)
You can emphasize or weaken the volume level of the Phone call, the
ring tone and the microphone input to fit your own preferences.
Setting contents:
PHONE TALK:
-5 dB ~ +5 dB
RING TONE:
-5 dB ~ +5 dB
MIC GAIN:
-5 dB ~ +5 dB
Note
• These setting items are the same as PHONE TALK, RING TONE and
MIC GAIN settings in AUDIO step mode, refer to “Setting the Source
Volume Level” on page 15.
Sound Auto setting (AUTO SET)
This unit provides 5 methods to improve the sound quality of calling.
You can choose the type according to your own preference.
Setting contents:
TYPE1 (Initial setting) / TYPE2 / TYPE3 / TYPE4 / TYPE5
TYPE1:
Standard Mode (recommended)
TYPE2:
Enhances the noise reduction
TYPE3:
Enhances the echo-cancel
TYPE4:
Enhances both noise reduction and echo-cancel
TYPE5:
Weakens both noise reduction and echo-cancel
Notes
• The functions below are designed to improve the sound quality of the
caller to driver.
Noise reduction: This function can reduce the road noise, but excessive
enhancement may affect the sound quality of calling.
Echo-cancel: This function can reduce the echo noise, but excessive
enhancement may affect the sound quality of calling.
• Improvement effect differs depending on the actual calling environment,
so please choose a suitable type accordingly.
You can choose whether to use these functions according to the
following setting.
 Setting item: SENDER ID
 Further setting items: MSG ALERT / CALLER ID
Setting contents:
OFF / ON (Initial setting)
Setting text message indicator ON/OFF
(MSG ALERT)
When it is set to ON, the h indicator blinks for 30 seconds while
receiving a text message. The h indicator remains on if there is an
unread text message on the connected mobile phone.
Notes
• Depending on the mobile phone, this function may not be performed.
• The text of the text message will not be displayed on this unit.
• When this unit prompts you of a received text message, it is
recommended to read the message after stopping your car in a safe
place, rather than read it immediately through your phone.
Setting the caller information display ON/OFF
(CALLER ID)
If you want to keep the ID information of the caller from others, set this
item to OFF. While you are dialing a number, telephone name will be
displayed as “ID UNSENT”. While a call is dialing in or during a call,
“NO NAME” will be displayed.
Setting the Visible Mode
Pairing a BLUETOOTH Device from the
unit
Setting the BLUETOOTH sound quality
Setting the caller information display/
text message indicator ON/OFF

Alpine CDE-W235BT Specifications

General

Audio system	4.0
MP3 playback	Yes
DVD Audio playback	No
Playback disc formats	CD audio
Audio formats supported	AAC, CD-A, MP3, WMA
Video formats supported	Not supported
AM band range	531 - 1602 kHz
FM band range	87.5 - 108 MHz
LW band range	153 - 281 kHz
Supported radio bands	FM, LW, MW
Preset stations quantity	30
Impedance	4 Ω
Output power	200 W
RDS features	RT, TA
Product color	Multicolor
Volume control	Digital
Disc types supported	CD, CD-R, CD-RW
Audio output channels	4.0 channels
Equalizer bands quantity	3
Display type	LCD
Display digits	28 digits
Display number of lines	2 lines
Video in	0
USB version	2.0
Bluetooth profiles	A2DP, AVRCP, HSP, SSP
USB ports quantity	1
Apple docking compatibility	iPhone, iPod
Material	Metal, Plastic
File format system	FAT 16/32
Power requirements	11 - 16 VDC
Compatible products	iPod / iPhone / Nokia
Key illumination color	Multi
Number of optical discs	1 discs
Operating temperature (T-T)	-10 - 60 °C

Weight and Dimensions

Depth	160 mm
Width	178 mm
Height	100 mm
Weight	1600 g
Dimensions (WxDxH)	178 x 160 x 100 mm
