Alpine CDE-W235BT Quick Reference Guide

33-EN
Specifications
FM TUNER SECTION
AM TUNER SECTION
CD PLAYER SECTION
USB SECTION
* Frequency response may differ depending on the encoder software/bit
rate.
BLUETOOTH SECTION
PICKUP
GENERAL
* Primary amplifier ratings per CEA-2006 Standard
• Power output: measured at 4 Ohms and ≤ 1% THD+N
• S/N: 80 dBA (reference: 1 W into 4 Ohms)
CHASSIS SIZE
Note
• Due to continuous product improvement, specifications and design are
subject to change without notice.
Tuning Range 87.7 ~ 107.9 MHz
Mono Usable Sensitivity 9.3 dBf (0.8 μV/75 ohms)
50 dB Quieting Sensitivity 13.5 dBf (1.3 μV/75 ohms)
Alternate Channel Selectivity 80 dB
Signal-to-Noise Ratio 65 dB
Stereo Separation 35 dB
Capture Ratio 2.0 dB
Tuning Range 530 ~ 1,710 kHz
Sensitivity (IEC Standard) 22.5 μV/27 dB
Frequency Response 5 ~ 20,000 Hz (±1 dB)
Wow & Flutter (% WRMS) Below measurable limits
Total Harmonic Distortion 0.008% (at 1 kHz)
Dynamic Range 95 dB (at 1 kHz)
Signal-to-Noise Ratio 105 dB
Channel Separation 85 dB (at 1 kHz)
USB requirements USB 1.1/2.0
Max. Power Consumption 1,000 mA
USB Class Mass Storage
File System FAT 12/16/32
MP3 Decoding MPEG AUDIO Layer-3
WMA Decoding Windows Media
™
Audio
Number of Channels 2-Channel (Stereo)
Frequency Response
*
5 ~ 20,000 Hz (±1 dB)
Total Harmonic Distortion 0.008% (at 1 kHz)
Dynamic Range 95 dB (at 1 kHz)
Signal-to-Noise Ratio 105 dB
Channel Separation 85 dB (at 1 kHz)
BLUETOOTH Specification BLUETOOTH V 3.0
Output Power +4 dBm Max. (Power class 2)
Profile HFP (Hands-Free Profile)
HSP (Head Set Profile)
A2DP (Advanced Audio
Distribution Profile)
AVRCP (Audio/Video Remote
Control Profile)
Wave length 795 nm
Laser power CLASS I
Power Requirement 14.4 V DC
(11 ~ 16 V allowable)
Power Output 18 W RMS × 4
*
Maximum Pre-Output Voltage 2 V/10 k ohms
Bass ±14 dB at 100 Hz
Mid ±14 dB at 1 kHz
Treble ±14 dB at 10 kHz
Loudness 10 dB at 100 Hz
Weight 1.618 kg (3 lbs. 9 oz)
Width 178 mm (7")
Height 100 mm (3–15/16")
Depth 160 mm (6–1/4")

Alpine CDE-W235BT Specifications

General

Audio system	4.0
MP3 playback	Yes
DVD Audio playback	No
Playback disc formats	CD audio
Audio formats supported	AAC, CD-A, MP3, WMA
Video formats supported	Not supported
AM band range	531 - 1602 kHz
FM band range	87.5 - 108 MHz
LW band range	153 - 281 kHz
Supported radio bands	FM, LW, MW
Preset stations quantity	30
Impedance	4 Ω
Output power	200 W
RDS features	RT, TA
Product color	Multicolor
Volume control	Digital
Disc types supported	CD, CD-R, CD-RW
Audio output channels	4.0 channels
Equalizer bands quantity	3
Display type	LCD
Display digits	28 digits
Display number of lines	2 lines
Video in	0
USB version	2.0
Bluetooth profiles	A2DP, AVRCP, HSP, SSP
USB ports quantity	1
Apple docking compatibility	iPhone, iPod
Material	Metal, Plastic
File format system	FAT 16/32
Power requirements	11 - 16 VDC
Compatible products	iPod / iPhone / Nokia
Key illumination color	Multi
Number of optical discs	1 discs
Operating temperature (T-T)	-10 - 60 °C

Weight and Dimensions

Depth	160 mm
Width	178 mm
Height	100 mm
Weight	1600 g
Dimensions (WxDxH)	178 x 160 x 100 mm
