Alpine CDE-W235BT Quick Reference Guide

26-EN
While calling, activating the Voice Mute function will instantly mute the
microphone input. Your voice will not be heard by the caller.
While calling, press  to mute the microphone input.
Press  again will bring the microphone input back to its
previous volume level.
Note
• The operation can also be performed in the option menu of phone mode
(calling mode). Refer to “Option Menu Setting” on page 17.
While making a call, this function allows you to initiate the transfer of
the audio between the mobile phone and the speakers in the car.
While calling, press BAND to switch the call sound
between the unit and mobile phone.
Notes
• Depending on the mobile phone, this operation may not be performed.
• The operation can also be performed in the option menu of phone mode
(calling mode). Refer to “Option Menu Setting” on page 17.
BLUETOOTH Audio Operation
Audio information of a BLUETOOTH compatible mobile phone, a
portable player, etc., is controllable/playable wirelessly
*
from this unit.
* To play back audio, a mobile phone or a portable player conforming to
A2DP (Advanced Audio Distribution Profile) and AVRCP (Audio/
Video Remote Control Profile) is required.
Not all functions work with all devices.
Notes
• Set “AUDIO” to ON when you want to use BLUETOOTH Audio
function. Refer to “Setting the BLUETOOTH Connection (BT IN)” on
page 21.
• During a call, sound on the BLUETOOTH audio source is muted.
• If you operate the Hands-free phone (e.g. searching in the phonebook)
while using the BLUETOOTH Audio function, BLUETOOTH Audio
playback may be affected.
Press SOURCE/ to select the BT AUDIO mode.
Press .
Returns the beginning of the song being played back.
Press .
Forwards the next song.
Pressing and holding  or  will fast backward/fast
forward track continuously.
Press .
A playback stops. Touching again will resume a playback.
Playing MP3/WMA Files from Flash Memory
(optional)
If a Flash Memory device is connected to the unit, MP3/WMA files can
be played back.
1 Press SOURCE to switch to the USB AUDIO mode.
2 To pause playback, press .
Pressing  again will resume the playback.
Notes
• The root folder is displayed as “ROOT” in the Folder Name Search
mode.
• This unit plays back files in Flash Memory with the same controls and
modes as playback of CDs containing MP3/WMA. For details, refer to
“CD/MP3/WMA” on page 10.
• Before disconnecting Flash Memory, be sure to change to another source
or set to pause.
• The playback time may not be correctly displayed when a VBR
(Variable Bit Rate) recorded file is played back.
Muting the microphone input quickly
(Voice Mute)
Call Switching Operation
Recalling the BLUETOOTH Audio Mode
Selecting the desired Song
Pausing
Flash Memory (optional)
SOURCE/


Alpine CDE-W235BT Specifications

General

Audio system	4.0
MP3 playback	Yes
DVD Audio playback	No
Playback disc formats	CD audio
Audio formats supported	AAC, CD-A, MP3, WMA
Video formats supported	Not supported
AM band range	531 - 1602 kHz
FM band range	87.5 - 108 MHz
LW band range	153 - 281 kHz
Supported radio bands	FM, LW, MW
Preset stations quantity	30
Impedance	4 Ω
Output power	200 W
RDS features	RT, TA
Product color	Multicolor
Volume control	Digital
Disc types supported	CD, CD-R, CD-RW
Audio output channels	4.0 channels
Equalizer bands quantity	3
Display type	LCD
Display digits	28 digits
Display number of lines	2 lines
Video in	0
USB version	2.0
Bluetooth profiles	A2DP, AVRCP, HSP, SSP
USB ports quantity	1
Apple docking compatibility	iPhone, iPod
Material	Metal, Plastic
File format system	FAT 16/32
Power requirements	11 - 16 VDC
Compatible products	iPod / iPhone / Nokia
Key illumination color	Multi
Number of optical discs	1 discs
Operating temperature (T-T)	-10 - 60 °C

Weight and Dimensions

Depth	160 mm
Width	178 mm
Height	100 mm
Weight	1600 g
Dimensions (WxDxH)	178 x 160 x 100 mm
