Alpine CDE-W235BT User Manual

34-EN
Playback
1 Press SOURCE to switch to the iPod mode.
2 Press  or  to select the desired song.
Pressing and holding  or  will fast backward/fast
forward the current track.
3 To pause playback, press .
Pressing  again will resume playback.
Notes
• A song playing on the iPod/iPhone while it is connected to this unit will
continue to play from where it was paused after disconnection.
• If you listen to an episode from a selected Podcast or Audiobook, the
episode can be changed by pressing  or .
• An episode may have several chapters. The chapter can be changed by
pressing  or .
• During iPod/iPhone playback, press , and then you can quickly
return to the hierarchy level selected last time in the search mode.
Searching for a desired Song
An iPod/iPhone can contain thousands of songs. The unit for this reason
can make various searches using the search function as shown below.
Each music category has its own individual hierarchy. Use the Playlist/
Artist/Album/Song/Podcast/Genre/Composer/Audiobook search mode
to narrow searches based on the table below.
Note
• You can select your preferred search mode. Refer to “iPod/iPhone
Search Mode Setting” on page 24.
For example:
Searching by Artist name
The following example explains how an ARTIST search is performed.
Another search mode can be used for the same operation, although the
hierarchy differs.
1 Press ENTER to activate the search selection mode.
The “” indicator lights up.
2 Turn the Rotary encoder to select the ARTIST search
mode, and then press ENTER.
SHUFFLE ALL
*1
 PLAYLIST  ARTIST  ALBUM  SONG 
PODCAST  GENRE  COMPOSER  AUDIOBOOK  SHUFFLE
ALL
*1 Refer to “Random Play Shuffle (M.I.X.)” on page 35.
Note
• The display of search mode list varies depending on the setting of IPOD
LIST. For details, refer to “iPod/iPhone Search Mode Setting” on
page 24.
3 Turn the Rotary encoder to select the desired Artist, and
then press ENTER.
4 Turn the Rotary encoder to select the desired Album, and
then press ENTER.
5 Turn the Rotary encoder to select the desired Song, and
then press ENTER.
Notes
• After pressing and holding ENTER for at least 2 seconds while in
each hierarchy (except SONG and AUDIOBOOK hierarchy), all songs
of the selected hierarchy are played back.
• After selecting [ALL] in the search mode with“
*
”, (refer to the table on
the left column) press and hold ENTER for at least 2 seconds to play
back all songs in the iPod/iPhone or selected search mode.
• While in the search mode, if you press and hold  for 2 seconds, or no
operation is performed for 10 seconds, the search mode is cancelled.
• In the search mode, pressing  will return to the previous mode.
• When search is made during M.I.X. play, the M.I.X. play mode will be
cancelled.
• “NO SONG” will be displayed if there are no songs in the selected
playlist in the PLAYLIST search mode.
• “NO PODCAST” will be displayed if there is no podcast data in the
iPod/iPhone in the PODCAST search mode.
• “NOAUDIOBOK” will be displayed if there is no audiobook data in the
iPod/iPhone in AUDIOBOOK search mode.
• If “iPod name” stored in the iPod/iPhone is selected in the desired
Playlist search mode, and ENTER is pressed, you can search for all
songs in the iPod/iPhone. Also, if you press and hold ENTER for at
least 2 seconds, all songs in the iPod/iPhone are played back.
• Depending on the iPod/iPhone, podcast search is not supported.
• If any one of the preset buttons (1 through 6) is pressed in the
search mode, a search can be made quickly by skipping to the specified
location. For details, refer to “Direct Search Function” on page 35.
Alphabet search function
The unit’s alphabet search function can be used to search for an album,
song, etc., more efficiently. In PLAYLIST/ARTIST/ALBUM/SONG/
PODCAST/GENRE/COMPOSER/AUDIOBOOK search mode, select
the first letter of your desired title (album, song, etc.), the titles
beginning with this letter are listed. By using this function, you can
quickly target any song.
1 In the search mode, press ABC SKIP.
The letter selection list is displayed.
2 Turn the Rotary encoder to select a desired letter (e.g. M),
and then press ENTER.
The titles beginning with “M” are listed.
3 Turn the Rotary encoder to select the desired title.
Notes
• While in Alphabet search mode, pressing  will return to the
previous mode.
• If the PLAYLIST search mode is used to search for a song, the Alphabet
search function is inactive in the song search hierarchy.
Hierarchy 1 Hierarchy 2 Hierarchy 3 Hierarchy 4
Playlist Song — —
Artist
*
Album
*
Song —
Album
*
Song — —
Song———
Podcast Episode — —
Genre
*
Artist
*
Album
*
Song
Composer
*
Album
*
Song —
Audiobook———

Alpine CDE-W235BT Specifications

General

Audio system	4.0
MP3 playback	Yes
DVD Audio playback	No
Playback disc formats	CD audio
Audio formats supported	AAC, CD-A, MP3, WMA
Video formats supported	Not supported
AM band range	531 - 1602 kHz
FM band range	87.5 - 108 MHz
LW band range	153 - 281 kHz
Supported radio bands	FM, LW, MW
Preset stations quantity	30
Impedance	4 Ω
Output power	200 W
RDS features	RT, TA
Product color	Multicolor
Volume control	Digital
Disc types supported	CD, CD-R, CD-RW
Audio output channels	4.0 channels
Equalizer bands quantity	3
Display type	LCD
Display digits	28 digits
Display number of lines	2 lines
Video in	0
USB version	2.0
Bluetooth profiles	A2DP, AVRCP, HSP, SSP
USB ports quantity	1
Apple docking compatibility	iPhone, iPod
Material	Metal, Plastic
File format system	FAT 16/32
Power requirements	11 - 16 VDC
Compatible products	iPod / iPhone / Nokia
Key illumination color	Multi
Number of optical discs	1 discs
Operating temperature (T-T)	-10 - 60 °C

Weight and Dimensions

Depth	160 mm
Width	178 mm
Height	100 mm
Weight	1600 g
Dimensions (WxDxH)	178 x 160 x 100 mm
