Alpine CDE-W235BT User Manual

39-EN
Specifications
FM TUNER SECTION
MW TUNER SECTION
LW TUNER SECTION
CD PLAYER SECTION
USB SECTION
* Frequency response may differ depending on the encoder software/bit
rate.
BLUETOOTH SECTION (CDE-W235BT only)
PICKUP
GENERAL
CHASSIS SIZE
Note
• Due to continuous product improvement, specifications and design are
subject to change without notice.
CAUTION
Tuning Range 87.5~108.0 MHz
Mono Usable Sensitivity 0.7 μV
Alternate Channel Selectivity 80 dB
Signal-to-Noise Ratio 65 dB
Stereo Separation 35 dB
Capture Ratio 2.0 dB
Tuning Range 531~1,602 kHz
Sensitivity (IEC Standard) 25.1 μV/28 dB
Tuning Range 153~281 kHz
Sensitivity (IEC Standard) 31.6 μV/30 dB
Frequency Response 5~20,000 Hz (±1 dB)
Wow & Flutter (% WRMS) Below measurable limits
Total Harmonic Distortion 0.008% (at 1 kHz)
Dynamic Range 95 dB (at 1 kHz)
Signal-to-Noise Ratio 105 dB
Channel Separation 85 dB (at 1 kHz)
USB requirements USB 1.1/2.0
Max. Power Consumption 1,000 mA
USB Class Mass Storage
File System FAT 12/16/32
MP3 Decoding MPEG AUDIO Layer-3
WMA Decoding Windows Media
™
Audio
AAC Decoding AAC-LC format “.m4a” file
Number of Channels 2-Channel (Stereo)
Frequency Response
*
5~20,000 Hz (±1 dB)
Total Harmonic Distortion 0.008% (at 1 kHz)
Dynamic Range 95 dB (at 1 kHz)
Signal-to-Noise Ratio 105 dB
Channel Separation 85 dB (at 1 kHz)
BLUETOOTH Specification BLUETOOTH V 3.0
Output Power +4 dBm Max. (Power class 2)
Profile HFP (Hands-Free Profile)
HSP (Head Set Profile)
A2DP (Advanced Audio
Distribution Profile)
AVRCP (Audio/Video Remote
Control Profile)
Wave length 795 nm
Laser power CLASS I
Power Requirement 14.4 V DC
(11~16 V allowable)
Maximum Power Output 50 W × 4
Maximum Pre-Output Voltage 2 V/10 k ohms
Bass ±14 dB at 60 Hz
Treble ±14 dB at 10 kHz
Loudness 10 dB at 100 Hz
Weight 1.618 kg (3 lbs. 9 oz)
Width 178 mm (7")
Height 100 mm (3–15/16")
Depth 160 mm (6–1/4")
CLASS 1
LASER PRODUCT
(Bottom side of player)

Alpine CDE-W235BT Specifications

General

Audio system	4.0
MP3 playback	Yes
DVD Audio playback	No
Playback disc formats	CD audio
Audio formats supported	AAC, CD-A, MP3, WMA
Video formats supported	Not supported
AM band range	531 - 1602 kHz
FM band range	87.5 - 108 MHz
LW band range	153 - 281 kHz
Supported radio bands	FM, LW, MW
Preset stations quantity	30
Impedance	4 Ω
Output power	200 W
RDS features	RT, TA
Product color	Multicolor
Volume control	Digital
Disc types supported	CD, CD-R, CD-RW
Audio output channels	4.0 channels
Equalizer bands quantity	3
Display type	LCD
Display digits	28 digits
Display number of lines	2 lines
Video in	0
USB version	2.0
Bluetooth profiles	A2DP, AVRCP, HSP, SSP
USB ports quantity	1
Apple docking compatibility	iPhone, iPod
Material	Metal, Plastic
File format system	FAT 16/32
Power requirements	11 - 16 VDC
Compatible products	iPod / iPhone / Nokia
Key illumination color	Multi
Number of optical discs	1 discs
Operating temperature (T-T)	-10 - 60 °C

Weight and Dimensions

Depth	160 mm
Width	178 mm
Height	100 mm
Weight	1600 g
Dimensions (WxDxH)	178 x 160 x 100 mm
