SCHEMATICS
Ve ct or ™ H Se ries ▪ S ervice Ma nual ▪ MN -4 654 4 ▪ Rev 0 1 ▪ 11/19
81
SCHEMATICS
VMC-WD-008237
S1
J1
J21
J12
INTERFACE BOARD SIDE A
J54
I2C
J38
J10
J3
J4
POWER SUPPLY
POSITIVE
SPEAKER

ON/OFF BOARD
USB PORT

CONNECT EITHER SIDE



SD CARD
LVIO CABLE
WIFI ANTENNA ATTACHED TO CONTROL PANEL GLASS
RS 485/232
CAPACITVE
TOUCH CABLE



















   












CONTROL BOARD




SPEAKER
CONNECT EITHER SIDE
NEGATIVE
TOP
OF OVEN
TOP
OF OVEN
INTERFACE BOARD SIDE B
J1 USB Host J3 Backlight J4 LCD interface J10 Speaker J12 12 VDC power J21 ON/OFF J38 Speaker J54 RS 485/232 Communication I2C Capacitive touch S1 DIP switches
BACKLIGHT CABLE
CAPACITIVE TOUCH CONTROLLER
RIBBON
BOARD
CABLE
CAPACITIVE TOUCH CONTROL PANEL GLASS
LCD INTERFACE CABLE
L C D
DIP SWITCHES
ALL OFF
SW 2 OFF
SW 1 OFF
ELECTRIC BONDING TAPE
VECTOR H ID CAPACITIVE TOUCH
NOT TO SCALE
J1
CN2
CN3
