use and maintenance Leonardo 125 - Leonardo 150 - Leonardo 250
Description

+Ì
IGNITION
Type C.D.I. / Inductive
C.D.I. / Inductive;
C.D.I. / 3A5-AP
Spark advance 8°
± 2° - before T.D.C. at 1600 rpm
minimum 10°
at 1500 rpm
maximum 32°
at 5000 rpm
SPARK PLUG
Standard NGK CR8E VX NGK DR8EA
Spark plug gap 0,6 – 0,7 mm
ELECTRIC
SYSTEM
Battery 12 V - 12 Ah
Fuses 20 - 15 - 7,5 A
Generator (with permanent magnet) 12 V - 180 W 12 V - 200 W
BULBS
Low/high beam 12 V - 35 / 35 W
Low/high beam
J U
12 V - 35 / 35 W
Front parking light 12 V - 3 W
Direction indicators 12 V - 10 W
Rear parking light/stoplight 12 V - 5/21 W
Number plate 12 V - 5 W
Dashboard lighting 12 V - 1,2 W
WARNING LIGHTS
Direction indicators 12 V - 2 W
Engine oil pressure
 +
12 V - 2 W
–
Engine oil change
Ì
–
12 V - 2 W
Low beam 12 V - 2 W
High beam 12 V - 2 W
Low fuel 12 V - 2 W

APRILIA LEONARDO 125 Specifications

General

Engine Type	Single cylinder, 4-stroke
Displacement	124 cc
Cooling System	Liquid cooled
Fuel System	Carburetor
Transmission	Automatic CVT
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Drum
Front Tire	120/70-12
Rear Tire	130/70-12
Width	700 mm
