5 6
• Remove the purple and blue terminal inputs connected to the microswitch shown in
Picture 1.
• Remove 1 pc of 4x16 inox magnetic screw in the container’s upper left corner, by
attaching the star bit to the chargeable gun.
• Flex the 2 tabs at the right and left side of the container by means of a tool such as a
knife and remove the container, as shown in Picture 3.
12.4.2. Microswitch
Used service number: 1264
1 2 3
• It operates by contact with the trigger in the microswitch container group.
• Remove the purple and blue cable inputs shown in Picture 1.
• Pull and remove the microswitch by flexing the tab which holds the microswitch
upwards as in Picture 2.
12.5. CRENEL
12.5.1. Beko crenel
Used service number: 1622
