SBS COSMOS REFRIGERATOR 07.11.2018 / REV NO: 01
76
Sensitivity: Public
When intervening the electronic boards, they should always be
controlled by taking measures such as ESD protected wrist strap,
heel protector, etc.
12.24. Pipe holder
Used service number: 1204
It ensures the water pipes passing over the back wall of the product to stay neatly.
Flex it by using a flat-tipped screwdriver and remove it from its housing at the back wall.
12.25. Quick fit
Used service number: 1514
Water pipe passing through water dispenser container of the fridge’s left door is
attached to the water pipe coming from the water valve by means of quick fit.
To Next Page
