arcelik BEKO G91634NE User Manual

SBS COSMOS REFRIGERATOR 07.11.2018 / REV NO: 01
61
Sensitivity: Public
12.4.2. Microswitch
Used service number: 1264
1 2 3
 It operates by contact with the trigger in the microswitch container group.
 Remove the purple and blue cable inputs shown in Picture 1.
 Pull and remove the microswitch by flexing the tab which holds the microswitch
upwards as in Picture 2.
12.5. CRENEL
12.5.1. Beko crenel
Used service number: 1622
 It is used in the container group.
 Remove by either using a flat tipped screwdriver, as shown in the picture, or pushing to
the rear corners.
12.6. WATER DISPENSER ILLUMINATION LED BOARD
12.6.1. Beko Light conducting LED board
Used service number: 1408
