arcelik BEKO G91634NE User Manual

SBS COSMOS
REFRIGERATOR 10.01.2014 / REV NO: 03
72
Sensitivity: Public
3 4
• First remove the upper hinge cover and then remove 2 pcs of PT (3x5) screws by
attaching the star bit to the chargeable gun.
• Remove the reed switch socket and other socket connections as shown in Picture 4
and 5.
• Remove M 4x5.5 screw fixing the earth cable by attaching the star bit to the chargeable
gun.
• Remove 3 pcs of M 5x18 spiral screws of the upper hinge by attaching a torque bit to
the chargeable gun.
12.16.2. Upper hinge right
Used service number: 1637
