Argo 2S User Manual

CH5 操作 Operation Original
33
5.2 機器控制 Machine controls
轉塔之旋轉 Swivel Turret
(1) 用固定板手，放鬆四個螺栓
Use spanner and unlock the 4 bolts.
(2) 旋轉至所需要的角度
Index to the required setting.
(3) 鎖緊四個螺栓
Lock the 4 bolts.
伸出臂之移動 Move Ram
Slide
(1) 放鬆兩支固定把手桿
Loosen two lock levers.
(2) 轉動控制把手至所需要之位置
Turn the handle to move the
slide to the desired position.
(3) 固定(先固定後面的把手桿)
Tighten, tightening the rear lock
lever first.
