Argo V890-23 User Manual

Electrical System Argo Service Manual
Ontario Drive & Gear Limited www.odg.com
PH.(519)- 662-2840 FAX (519)- 662-2421
ES-10
ES-2
3. Disconnect the bulb from the lens. Pry the 2 locking clips on the bulb apart while
pulling it from the wiring. Photo ES-3
ES-3
Installing a Headlamp Bulb
When installing the new bulb, avoid any contamination of the glass surface. Do not
touch the bulb with your fingers.
4. Clip the new bulb assembly into the wire harness.
5. Reaching in through the engine access area, align the bulb assembly with the head-
lamp housing. Push in and turn 1/4 turn clockwise.
Removing the Headlamp Lens Assembly (Conquest Models from CB12581)
1. Grabbing the rubber headlamp bezel, pull the lens assembly from the upper body.
Photo ES-4
2. Unclip the bulb from the wire harness as described in Photo ES-3
3. Peel the rubber headlamp bezel from the lense. Photo ES-6
ES-4 ES-6

Argo V890-23 Specifications

General

Brand	Argo
Model	V890-23
Category	Offroad Vehicle
Language	English

Summary

General Instructions and Safety Precautions

General Instructions and Cautions

Provides general servicing guidelines, safety precautions, and critical warnings for electrical system maintenance.

Component Service Procedures

Battery Maintenance and Service

Covers checking fluid, charging, cleaning terminals, removal, inspection, and installation procedures.

Headlamp Service Procedures

Details changing, removing, and installing headlamp bulbs and lenses for various models.

Starter Motor Removal and Installation

Explains the steps for removing and installing starter motors across different model series.

Brake Cooling Fan Service

Provides procedures for removing and installing the brake cooling fan assembly.

Electrical System Diagrams and Calibration

Wiring Diagrams by Model Series

Collection of detailed wiring diagrams for various Argo models and their specific years.

Digital Gauge Package Calibration

Step-by-step guide for re-calibrating or replacing the digital gauge package.
