Ariel JGQ User Manual

FOR MODELS: JGI, JGM, JGN, JGP AND JGQ SECTION 4 LUBRICATION
PAGE 4-22 9/08
Choosing a Lube System Monitor
When ordering an Ariel compressor the packager must choose a lube system monitor. See
the following table for the specifications on available types. For further information about
each device visit the vendor literature section of the Ariel web site.
I. Shutdown switch - This is a device that monitors the position of the divider block pin and
supplies a shutdown contact. If the divider block stops cycling for a given time a shutdown
signal will be sent to the control system.
APPLICATION NOTES - Shutdown Switch
Normally open (NO) vs. Normally closed (NC) Shutdown switch
TABLE 4-8 FORCE FEED LUBE SYSTEM MONITORS - SPECIFICATIONS
ITEM PROFLO KENCO DNFT
DNFT -
PROGRAMMABLE
Shutdown Signal YES NO YES YES
Proximity Signal YES (0.5 sec pulse) YES (switch) YES (switch) YES (switch)
Local Data Storage YES NO NO Count Display
Infrared Port YES NO NO NO
PLC Creates
Shutdown
NO YES NO NO
Remote Mounting YES NO NO NO
Area Classification CSA CSA CSA, CE, EX, ATEX CSA, CE
CSA 203633 Class I,
Div 2, Groups
ABCD T4A
044787 Class I,
Groups ABCD:
Class II, Groups EFG:
Class III
108334 Class I, Div
1 Groups ABCD T5;
&/or Class I, Zone 1
Ex md IIC T5
108334 Class I, Div 1
Groups ABCD T5; &/or
Class I, Zone 1 Ex md
IIC T5
CE N/A N/A 0344 Class I Div 1;
Groups ABCD T4
0344 Class I Div 1;
Groups ABCD T4
EX N/A N/A II 2G EEx mIIB T5 N/A
KEMA N/A N/A 00ATEX1090X/
AMB. -40°C to
+85°C
N/A
Battery (2) Standard Alka-
line “AA” Size
None Ariel P/N A-10807 Ariel P/N A-10807
Cost Factor New Unit $0 Standard Minus $ $0 Standard for CE Plus $
Shutdown Time Programmable PLC 3 minutes Programmable
20 sec. to 4 minutes
Temperature to185°F (85°C) to 220°F (104°C) -40°F to +185°F (-
40°C to +85°C)
-40°F to +185°F
(-40°C to +85°C)
Max. Switch Voltage 36 VDC 200 VAC/VDC 240 VDC 10 to 120 VAC
Max. Switch Current 0.5 Amps 0.5 Amps N/A N/A
Max. Switch Power N/A 10 Watts DC 2.5 VA 2.5 VA
Local Cycle Indicator YES - LCD Separate Indicator YES - Flashing LED YES -
LCD Display +LED
De-bounce Included NO NO YES YES
