FOR MODELS: JGI, JGM, JGN, JGP AND JGQ SECTION 4 LUBRICATION
PAGE 4-26 9/08
NOTE: WHEN THERE ARE LIQUIDS PRESENT IN THE GAS, THE MOST EFFECTIVE
LUBRICATION OF CYLINDERS AND PACKING REQUIRES REMOVAL OF THE
LIQUIDS BEFORE THE GAS ENTERS THE COMPRESSOR.
THESE LUBRICATION RECOMMENDATIONS ARE GENERAL GUIDELINES. IF
THE RECOMMENDED LUBRICANTS OR FLOW RATES DO NOT APPEAR TO
WORK ADEQUATELY, FLOW RATES AND/OR LUBRICANT TYPES MAY NEED
TO BE CHANGED. PLEASE CONTACT THE LUBRICANT SUPPLIER FOR SPE-
CIFIC LUBRICANT RECOMMENDATIONS.
WARRANTY OF COMPONENT FAILURES WHICH OCCUR WHILE USING
LUBRICANTS WHICH DO NOT MEET THESE SPECIFICATIONS WILL BE SUB-
JECT TO REVIEW ON A CASE BY CASE BASIS.
Lube Type & Rate Recommendations
TABLE 4-9 CYLINDER/PACKING LUBE OIL RECOMMENDATIONS FOR VARIOUS GAS STREAM COMPO-
NENTS
GAS STREAM
CYLINDER DISCHARGE PRESSURE
< 1000
PSIG
< (70 bar
g
)
1000 TO 2000
PSIG
(70 to 140 bar
g
)
2000 TO 3500
PSIG
(140 TO 240 bar
g
)
A
3500 TO 5000
PSIG
(240 to 345 bar
g
)
1
> 5000
PSIG
> (345 bar
g
)
1
Pipeline Quality
Natural Gas
Including CNG
(Dry)
SAE 40 wt.
ISO 150
1 x Base Rate
or Various
Synthetics
1 x Base Rate
SAE 40-50 wt.
ISO 150 - 220
1.25 x Base Rate
or Various
Synthetics
1 x Base Rate
SAE 50 wt.
ISO 220
w/ Compounding
1.5 x Base Rate
or Various
Synthetics
1.25 x Base Rate
Cylinder Oil
ISO 320 - 460
w/ Compounding
2 x Base Rate
or Synthetic -
Diester/Polyglycol
1.5 x Base Rate
Cylinder Oil
ISO 460 - 680
w/ Compounding
3 x Base Rate
or Synthetic -
Polyglycol
2 x Base Rate
Natural Gas
(Water
Saturated,
and/or Heavy
Hydrocarbons
b
Methane < 90%
Propane > 8%
SG > 0.7)
SAE 40 - 50 wt.
ISO 150 - 220
1.25 x Base Rate
or Various
Synthetics
1 x Base Rate
SAE 50 - 60 wt.
ISO 220 - 320
or SAE 40 wt.
ISO 150
w/ Compounding
1.5 x Base Rate
or Var. Synthetics
1.25 x Base Rate
Cylinder Oil
ISO 460 - 680
w/ Compounding
2 x Base Rate
or Various
Synthetics
1.5 x Base Rate
Cylinder Oil
ISO 680
w/ Compounding
3 x Base Rate
or Synthetic -
Diester/Polyglycol
2 x Base Rate
Contact Lubricant
Supplier
Natural Gas
(Water
Saturated and
Carbon Dioxide
> 2% to 10%)
SAE 40 - 50 wt.
ISO 150 - 220
1.25 x Base Rate
or Various
Synthetics
Base Rate
SAE 50 - 60 wt.
ISO 220 - 320
or SAE 40 wt.
ISO 150
w/ Compounding
1.5 x Base Rate
or Var. Synthetics
1.25 x Base Rate
Cylinder Oil
ISO 460-680
w/ Compounding
2 x Base Rate
or Synthetic PAG
1.5 x Base Rate
Cylinder Oil
ISO 680
w/ Compounding
3 x Base Rate
or Synthetic PAG
2 x Base Rate
Contact Lubricant
Supplier
