Ariel JGQ User Manual

FOR MODELS: JGI, JGM, JGN, JGP AND JGQ SECTION 4 LUBRICATION
PAGE 4-30 9/08
Water-Cooled Packing
0 1000 2000 3000 4000 5000
500
600
700
800
900
1000
1100
1200
69 138 207 276 345
254
305
356
406
457
508
559
610
Standard
Packing &
Lubrication
REGION
2
Increased
Viscocity
Lubricant
from Separate
Supply
AND
Water-Cooled
Packing
Mean Pressure, psi = (Pd + Ps) ÷ 2
Piston Speed, FPM
REGION
1
FIGURE 4-8 COMPRESSOR PACKING APPLICATION GUIDE-
LINES FOR PIPELINE QUALITY NATURAL GAS
Increased
Viscosity
Lubricant
from
Separate
Supply
OR
Water-Cooled
Packing
REGION 4
Cylinders are Not To Be
Applied In This Region
Without Prior Ariel
Approval.
REGION
3
Piston Speed, cm/s
Mean Pressure, bar = (Pd + Ps) ÷ 2
Water-cooled packing
cases are required for
compressor cylinders
based upon the average
piston speed and aver-
age cylinder pressure.
Cooled packing cases
are supplied to help
remove heat generated
as the piston rod/packing
friction increases with the
higher pressures and
piston speed.
Cooled packing cases
are required for cylin-
ders in accordance with
Figure 4-8.
FIGURE 4-9 WATER-COOLED PACKING CASE - TYPICAL
Coolant
In
Coolant
Out
Coolant In
Coolant Out
Coolant Flow
1. All cylinders that have water-
cooled packing as standard (see
Ariel Performance Program) must
be connected to a water cooling
system, unless prior approval is
obtained from Ariel Technical Ser-
vices.
2. If a separate lube supply is
needed due to the gas analysis
(H
2
S, CO
2
, water saturation, air,
etc.) an additional increase in vis-
cosity may be needed if the cooling
connection to a water cooled p
acking case is ommitted. Contact Ariel Technical Services for
assistance.
3. Cooling water quality and treatment is to be maintained to prevent corrosion and mineral
or other deposits. Cooling water must be treated with an appropriate anti-freeze, such as
glycol, if subject to freezing.
1.25 x 130 mm x 0.0074 L/day/mm =
1.2
N/A (1.2)
Recommended Total, (L/day) = (6.6)
TABLE 4-11 EXAMPLE CYLINDER & PACKING LUBE CALCULATION
US pints per day; ppd
