Asus B150M-A D3 User Manual

1-12
Chapter 1: Product introduction
1.7 Connectors
1.7.1 Rear panel connectors
2
4 53
6
8 7
1
11
910
LAN port
SPEED
LED
ACT/LINK
LED
4. Line In port (light blue).Thisportconnectstothetape,CD,DVDplayer,orother
audio sources.
5. Line Out port (lime). Thisportconnectstoaheadphoneoraspeaker.Inthe4.1,5.1,
and7.1-channelcongurations,thefunctionofthisportbecomesFrontSpeakerOut.
6. Microphone port (pink). This port connects to a microphone.
Refertotheaudiocongurationtableonthenextpageforthefunctionoftheaudioportsin
2.1,4.1,5.1,or7.1-channelconguration.
Activity/Link LED Speed LED
Status Description Status Description
Off Nolink OFF 10Mbpsconnection
Orange Linked ORANGE 100Mbpsconnection
Orange
(Blinking)
Dataactivity GREEN 1Gbps connection
Orange
(Blinkingthen
steady)
Readyto
wake up from
S5mode
_ _
1. PS/2 mouse port (green).ThisportisforaPS/2mouse.
2. Video Graphics Adapter (VGA) port. This15-pinportisforaVGAmonitororother
VGA-compatibledevices.
3. LAN (RJ-45) port.TheseportsallowGigabitconnectiontoaLocalAreaNetwork
(LAN)throughanetworkhub.
LAN port LED indications

Asus B150M-A D3 Specifications

General

Form Factor	Micro ATX
Chipset	Intel B150
Socket	LGA 1151
Memory Type	DDR3
Memory Slots	4
Maximum Memory	64GB
PCIe x16 Slots	1
PCIe x1 Slots	2
SATA Ports	6 x SATA 6Gb/s
Audio	Realtek ALC887 8-Channel High Definition Audio CODEC
USB 2.0 Ports	6
LAN	Realtek RTL8111H Gigabit LAN
Video Outputs	VGA, HDMI
