Asus K73SV User Manual

Notebook PC User Manual A-29
Wireless Operation Channel for Different Domains
N. America 2.412-2.462 GHz Ch01 through CH11
Japan 2.412-2.484 GHz Ch01 through Ch14
Europe ETSI 2.412-2.472 GHz Ch01 through Ch13
France Restricted Wireless Frequency Bands
Some areas of France have a restricted frequency band. The worst
case maximum authorized power indoors are:
• 10mW for the entire 2.4 GHz band (2400 MHz–2483.5 MHz)
• 100mW for frequencies between 2446.5 MHz and 2483.5 MHz
Channels 10 through 13 inclusive operate in the band 2446.6 MHz to
2483.5 MHz.
There are few possibilities for outdoor use: On private property or on
the private property of public persons, use is subject to a preliminary
authorization procedure by the Ministry of Defense, with maximum
authorized power of 100mW in the 2446.5–2483.5 MHz band. Use
outdoors on public property is not permitted.
In the departments listed below, for the entire 2.4 GHz band:
• Maximum authorized power indoors is 100mW
• Maximum authorized power outdoors is 10mW
Departments in which the use of the 2400–2483.5 MHz band is
permitted with an EIRP of less than 100mW indoors and less than
10mW outdoors:
01 Ain 02 Aisne 03 Allier
05 Hautes Alpes 08 Ardennes 09 Ariège
11 Aude 12 Aveyron 16 Charente
24 Dordogne 25 Doubs 26 Drôme
32 Gers 36 Indre 37 Indre et Loire
41 Loir et Cher 45 Loiret 50 Manche
55 Meuse 58 Nièvre 59 Nord

Asus K73SV Specifications

General

Graphics	NVIDIA GeForce GT 540M
Card Reader	3 -in-1 card reader ( SD/ MS/ MMC)
Networking	Integrated 802.11 b/g/n
LAN	10/100/1000 Base T
Battery	6Cells : 5200 mAh 56 Whrs
HDMI	1 x HDMI
Wi-Fi	802.11 b/g/n
Processor	Intel Core i7 2630QM / i5 2410M / i3 2310M
Display	17.3-inch HD (1600x900) or Full HD (1920x1080)
RAM	Up to 8GB DDR3
Storage	500GB
Operating System	Windows 7 Home Premium
CPU	Intel Core i7 2630QM / i5 2410M / i3 2310M
Chipset	Intel HM65
Memory	Up to 8GB DDR3
Display Options	17.3-inch HD (1600x900) or Full HD (1920x1080)
Graphics VRAM	1GB/2GB DDR3
Storage Options	500GB
Optical Drive	DVD Super Multi
Camera	0.3 Mega Pixel web camera
Bluetooth	Bluetooth V3.0+HS (optional)
Interface	1 x Microphone-in jack, 1 x Headphone-out jack, 1 x VGA port/Mini D-sub 15-pin for external monitor, 3 x USB 2.0 port(s), 1 x USB 3.0 port(s), 1 x RJ45 LAN Jack for LAN insert, 1 x HDMI
Audio	Built-in Speakers And Microphone
Power Adapter	Output : 19 V DC, 4.74 A, 90 W Input : 100 -240 V AC, 50/60 Hz universal
Optical Drive Type	DVD Super Multi
USB Ports	3 x USB 2.0 port(s), 1 x USB 3.0 port(s)
Weight	3.3 kg (with 6-cell battery)
