Asus K73SV User Manual

Notebook PC User Manual 31
IMPORTANT! Only use battery packs and power adapters
supplied with this Notebook PC or specifically approved by the
manufacturer or retailer for use with this model or else damage
may occur to the Notebook PC.
To remove the battery pack:
WARNING! For safety reasons, DO NOT throw the battery in fire,
DO NOT short circuit the contacts, and DO NOT disassemble the
battery. If there is any abnormal operation or damage to the
battery pack caused by impact, turn OFF the Notebook PC and
contact an authorized service center.
Battery Care
The Notebook PC’s battery pack, like all rechargeable batteries, has
a limit on the number times it can be recharged. The battery pack’s
useful life will depend on your environment temperature, humidity,
and how your Notebook PC is used. It is ideal that the battery be
used in a temperature range between 10˚C and 35˚C (50˚F and
95˚F). You must also take into account that the Notebook PC’s
internal temperature is higher than the outside temperature. Any
temperatures above or below this range will shorten the life of the
battery. But in any case, the battery pack’s usage time will eventually
decrease and a new battery pack must be purchased from an
authorized dealer for this Notebook PC. Because batteries also have
a shelf life, it is not recommended to buy extras for storing.
3

2
1
2
3
1

Asus K73SV Specifications

General

Graphics	NVIDIA GeForce GT 540M
Card Reader	3 -in-1 card reader ( SD/ MS/ MMC)
Networking	Integrated 802.11 b/g/n
LAN	10/100/1000 Base T
Battery	6Cells : 5200 mAh 56 Whrs
HDMI	1 x HDMI
Wi-Fi	802.11 b/g/n
Processor	Intel Core i7 2630QM / i5 2410M / i3 2310M
Display	17.3-inch HD (1600x900) or Full HD (1920x1080)
RAM	Up to 8GB DDR3
Storage	500GB
Operating System	Windows 7 Home Premium
CPU	Intel Core i7 2630QM / i5 2410M / i3 2310M
Chipset	Intel HM65
Memory	Up to 8GB DDR3
Display Options	17.3-inch HD (1600x900) or Full HD (1920x1080)
Graphics VRAM	1GB/2GB DDR3
Storage Options	500GB
Optical Drive	DVD Super Multi
Camera	0.3 Mega Pixel web camera
Bluetooth	Bluetooth V3.0+HS (optional)
Interface	1 x Microphone-in jack, 1 x Headphone-out jack, 1 x VGA port/Mini D-sub 15-pin for external monitor, 3 x USB 2.0 port(s), 1 x USB 3.0 port(s), 1 x RJ45 LAN Jack for LAN insert, 1 x HDMI
Audio	Built-in Speakers And Microphone
Power Adapter	Output : 19 V DC, 4.74 A, 90 W Input : 100 -240 V AC, 50/60 Hz universal
Optical Drive Type	DVD Super Multi
USB Ports	3 x USB 2.0 port(s), 1 x USB 3.0 port(s)
Weight	3.3 kg (with 6-cell battery)
