Asus K73SV User Manual

66 Notebook PC User Manual
The built-in network cannot be installed later as an upgrade.
After purchase, network can be installed as an expansion card.
Connections
Network Connection
Connect a network cable, with RJ-45 connectors on each end, to the
modem/network port on the Notebook PC and the other end to a
hub or switch. For 100 BASE-TX / 1000 BASE-T speeds, your network
cable must be category 5 or better (not category 3) with twisted-pair
wiring. If you plan on running the interface at 100/1000Mbps, it must
be connected to a 100 BASE-TX / 1000 BASE-T hub (not a BASE-T4
hub). For 10Base-T, use category 3, 4, or 5 twisted-pair wiring. 10/100
Mbps Full-Duplex is supported on this Notebook PC but requires
connection to a network switching hub with “duplex” enabled. The
software default is to use the fastest setting so no user-intervention
is required.
1000BASE-T (or Gigabit) is only supported on selected models.

Asus K73SV Specifications

General

Graphics	NVIDIA GeForce GT 540M
Card Reader	3 -in-1 card reader ( SD/ MS/ MMC)
Networking	Integrated 802.11 b/g/n
LAN	10/100/1000 Base T
Battery	6Cells : 5200 mAh 56 Whrs
HDMI	1 x HDMI
Wi-Fi	802.11 b/g/n
Processor	Intel Core i7 2630QM / i5 2410M / i3 2310M
Display	17.3-inch HD (1600x900) or Full HD (1920x1080)
RAM	Up to 8GB DDR3
Storage	500GB
Operating System	Windows 7 Home Premium
CPU	Intel Core i7 2630QM / i5 2410M / i3 2310M
Chipset	Intel HM65
Memory	Up to 8GB DDR3
Display Options	17.3-inch HD (1600x900) or Full HD (1920x1080)
Graphics VRAM	1GB/2GB DDR3
Storage Options	500GB
Optical Drive	DVD Super Multi
Camera	0.3 Mega Pixel web camera
Bluetooth	Bluetooth V3.0+HS (optional)
Interface	1 x Microphone-in jack, 1 x Headphone-out jack, 1 x VGA port/Mini D-sub 15-pin for external monitor, 3 x USB 2.0 port(s), 1 x USB 3.0 port(s), 1 x RJ45 LAN Jack for LAN insert, 1 x HDMI
Audio	Built-in Speakers And Microphone
Power Adapter	Output : 19 V DC, 4.74 A, 90 W Input : 100 -240 V AC, 50/60 Hz universal
Optical Drive Type	DVD Super Multi
USB Ports	3 x USB 2.0 port(s), 1 x USB 3.0 port(s)
Weight	3.3 kg (with 6-cell battery)
