20
Notebook PC User Manual
Right Side
1
2
HDMI
1 2 3 5 6 7 8 94
Headphone Output Jack
The stereo headphone jack (1/8 inch) is used to connect
the Notebook PC’s audio out signal to amplified speakers
or headphones. Using this jack automatically disables the
built-in speakers.
Microphone Input Jack
The mono microphone jack (1/8 inch) can be used to
connect an external microphone or output signals from
audio devices. Using this jack automatically disables the
built-in microphone. Use this feature for video conferencing,
voice narrations, or simple audio recordings.
USB Port (2.0)
The USB (Universal Serial Bus) port is compatible with USB
2.0 or USB 1.1 devices such as keyboards, pointing devices,
cameras, hard disk drives, printers, and scanners connected
in a series up to 12Mbits/sec (USB 1.1) and 480Mbits/sec
(USB 2.0). USB allows many devices to run simultaneously
on a single computer, with some peripherals acting as
additional plug-in sites or hubs. USB supports hot-swapping
of devices so that most peripherals can be connected or
disconnected without restarting the computer.
3

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Asus K73SV and is the answer not in the manual?

Asus K73SV Specifications

General IconGeneral
GraphicsNVIDIA GeForce GT 540M
Card Reader3 -in-1 card reader ( SD/ MS/ MMC)
NetworkingIntegrated 802.11 b/g/n
LAN10/100/1000 Base T
Battery6Cells : 5200 mAh 56 Whrs
HDMI1 x HDMI
Wi-Fi802.11 b/g/n
ProcessorIntel Core i7 2630QM / i5 2410M / i3 2310M
Display17.3-inch HD (1600x900) or Full HD (1920x1080)
RAMUp to 8GB DDR3
Storage500GB
Operating SystemWindows 7 Home Premium
CPUIntel Core i7 2630QM / i5 2410M / i3 2310M
ChipsetIntel HM65
MemoryUp to 8GB DDR3
Display Options17.3-inch HD (1600x900) or Full HD (1920x1080)
Graphics VRAM1GB/2GB DDR3
Storage Options500GB
Optical DriveDVD Super Multi
Camera0.3 Mega Pixel web camera
BluetoothBluetooth V3.0+HS (optional)
Interface1 x Microphone-in jack, 1 x Headphone-out jack, 1 x VGA port/Mini D-sub 15-pin for external monitor, 3 x USB 2.0 port(s), 1 x USB 3.0 port(s), 1 x RJ45 LAN Jack for LAN insert, 1 x HDMI
AudioBuilt-in Speakers And Microphone
Power AdapterOutput : 19 V DC, 4.74 A, 90 W Input : 100 -240 V AC, 50/60 Hz universal
Optical Drive TypeDVD Super Multi
USB Ports3 x USB 2.0 port(s), 1 x USB 3.0 port(s)
Weight3.3 kg (with 6-cell battery)
