Asus K73SV User Manual

30 Notebook PC User Manual
IMPORTANT! Never attempt to remove the battery pack while
the Notebook PC is turned ON, as this may result in the loss of
working data.
To install the battery pack:
Using Battery Power
The Notebook PC is designed to work with a removable battery pack.
The battery pack consists of a set of battery cells housed together.
A fully charged pack will provide several hours of battery life, which
can be further extended by using power management features
through the BIOS setup. Additional battery packs are optional and
can be purchased separately through a Notebook PC retailer.
Installing and Removing the Battery Pack
Your Notebook PC may or may not have its battery pack installed. If
your Notebook PC does not have its battery pack installed, use the
following procedures to install the battery pack.
3

2
1
2
3
1

Asus K73SV Specifications

General

Graphics	NVIDIA GeForce GT 540M
Card Reader	3 -in-1 card reader ( SD/ MS/ MMC)
Networking	Integrated 802.11 b/g/n
LAN	10/100/1000 Base T
Battery	6Cells : 5200 mAh 56 Whrs
HDMI	1 x HDMI
Wi-Fi	802.11 b/g/n
Processor	Intel Core i7 2630QM / i5 2410M / i3 2310M
Display	17.3-inch HD (1600x900) or Full HD (1920x1080)
RAM	Up to 8GB DDR3
Storage	500GB
Operating System	Windows 7 Home Premium
CPU	Intel Core i7 2630QM / i5 2410M / i3 2310M
Chipset	Intel HM65
Memory	Up to 8GB DDR3
Display Options	17.3-inch HD (1600x900) or Full HD (1920x1080)
Graphics VRAM	1GB/2GB DDR3
Storage Options	500GB
Optical Drive	DVD Super Multi
Camera	0.3 Mega Pixel web camera
Bluetooth	Bluetooth V3.0+HS (optional)
Interface	1 x Microphone-in jack, 1 x Headphone-out jack, 1 x VGA port/Mini D-sub 15-pin for external monitor, 3 x USB 2.0 port(s), 1 x USB 3.0 port(s), 1 x RJ45 LAN Jack for LAN insert, 1 x HDMI
Audio	Built-in Speakers And Microphone
Power Adapter	Output : 19 V DC, 4.74 A, 90 W Input : 100 -240 V AC, 50/60 Hz universal
Optical Drive Type	DVD Super Multi
USB Ports	3 x USB 2.0 port(s), 1 x USB 3.0 port(s)
Weight	3.3 kg (with 6-cell battery)
