Asus M2N-MX DVI2 User Manual

ASUS M2N-MX
2-2 1
2.4.3 Onboard Devices Configuration
Congure ITE8712 Super IO Chipset
Serial Port1 Address [3F8/IRQ4]
Parallel Port Address [378]
Parallel Port Mode [Normal]
Parallel Port IRQ [IRQ7]
Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address. Conguration options:
[Disabled] [3F8/IRQ4][2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]
Parallel Port Address [378]
Allows you to select the Parallel Port base addresses.
Conguration options: [Disabled] [378] [278] [3BC]
Parallel Port Mode [Normal]
Allows you to select the Parallel Port mode.
Conguration options: [Normal] [EPP] [ECP] [EPP+ECP]
ECP Mode DMA Channel [DMA3]
Appears only when the Parallel Port Mode is set to [ECP]. This item
allows you to set the Parallel Port ECP DMA.
Conguration options: [DMA0] [DMA1] [DMA3]
Parallel Port IRQ [IRQ7]
Conguration options: [IRQ5] [IRQ7]

Asus M2N-MX DVI2 Specifications

General

CPU Socket Type	AM2
PCI Express x16	1
PCI Express x1	1
PCI Slots	2
Audio Chipset	Realtek ALC662
Audio Channels	6
Max. LAN Speed	10/100 Mbps
Form Factor	Micro ATX
Memory Slots	2
Memory Standard	DDR2
SATA	4
IDE	1
LAN Chipset	Realtek RTL8201CL
Video Ports	DVI, VGA
