* LAN port LED indications
Activity/Link
Speed LED
Description
OFF OFF Soft-off Mode
Yellow Blinking OFF During Power ON/OFF
Yellow Blinking ORANGE 100 Mbps connection
Yellow Blinking GREEN 1 Gbps connection
Speed
LED
Activity/
Link LED
LAN port
Port
Headset
2-channel
4-channel 6-channel 8-channel
Light Blue Line In Line In Line In Line In
Lime Line Out Front Speaker Out Front Speaker Out Front Speaker Out
Pink Mic In Mic In Mic In Mic In
Orange – – Center/Subwoofer Center/Subwoofer
Black – Rear Speaker Out Rear Speaker Ou Rear Speaker Out
Gray – – – Side Speaker Out
2-30 Chapter 2: Hardware information
