Asus RS500A-S6/PS4 User Manual

3-5ASUS RS500A-S6/PS4
Rack railsFront endRear endNuts and screws
3.2 Installing optional ball-bearing rail kit
items
Your optional ball-bearing rail kit package contains:
• two pair of server rails (for the server)
• two pairs of rack rails (for the rack)
• Nut-and-bolt type screws
3.2.1 Attaching the rails to the server
To attach the server rails:
1. Attach the front end of the server rail to the side of the chassis, matching
each of the three hooks to the holes on the rail. Then slide the rail toward the
front panel until it locks in place.
2. Secure the front end of the server rail to the side of the chassis with one
screw.

Asus RS500A-S6/PS4 Specifications

General

Brand	Asus
Model	RS500A-S6/PS4
Category	Server
Language	English
