Asus RS500A-S6/PS4 User Manual

ASUS RS500A-S6/PS4 5-25
5.4.3 OnboardDevicesConguration
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
BIOS SETUP UTILITY
Advanced
Onboard Devices Conguration
Serial Port1 Address [3F8/IRQ4]
Serial Port2 Address [2F8/IRQ3]
Onboard LAN Chip [Enabled]
Onboard LAN1 Port [Enabled]
Onboard LAN2 Port [Enabled]
Onboard LAN3 Port [Enabled]
Onboard LAN4 Port [Enabled]
Onboard LAN1 Boot [PXE]
Onboard LAN2 Boot [PXE]
Onboard LAN3 Boot [PXE]
Onboard LAN4 Boot [PXE]
←→ Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
Allows BIOS to Select
Serial Port1 Base
Addresses.
Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Conguration options: [Disabled] [3F8/IRQ4] [3E8/IRQ4] [2E8/IRQ3]
Serial Port2 Address [2F8/IRQ3]
Allows you to select the Serial Port2 base address.
Conguration options: [Disabled] [2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]
Onboard LAN Chip [Enabled]
Enables or disables the onboard LAN controller.
Conguration options: [Disabled] [Enabled]
The following items appear only when you set
Onboard LAN Chip
to [Enabled].
Onboard LAN1/LAN2/LAN3/LAN4 Port [Enabled]
Enables or disables the onboard LAN1/2/3/4 port.
Conguration options: [Disabled] [Enabled]
Onboard LAN1/LAN2/LAN3/LAN4 Boot [PXE]
Allows you to congure the onboard LAN1/2/3/4 boot mode.
Conguration options: [Disabled] [PXE] [iSCSI]
