5-32 Chapter 5: BIOS setup
5.6.6 Hardware Monitor
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
BIOS SETUP UTILITY
Power
Hardware Monitor
CPU1 Temperature [ 38 ºC/ 100 ºF]
CPU2 Temperature [ N/A ]
TR1 Temperature [ N/A ]
TR2 Temperature [ N/A ]
CPU Fan1 Speed [ 904 RPM]
CPU Fan2 Speed [ N/A ]
Front Fan1 Speed [ N/A ]
Front Fan2 Speed [ N/A ]
Front Fan3 Speed [ N/A ]
Front Fan4 Speed [ N/A ]
Front Fan5 Speed [ N/A ]
Front Fan6 Speed [ N/A ]
Rear Fan1 Speed [ N/A ]
Fan Speed Control [Generic Mode]
VCORE1 Voltage [ 1.090 V]
VCORE2 Voltage [ N/A ]
P1DDR3 Voltage [ 1.532 V]
P2DDR3 Voltage [ N/A ]
←→ Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
Scroll down for more items.
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
P1_+1.2V Voltage [ 1.220 V]
P2_+1.2V Voltage [ N/A ]
P1_VDDNB Voltage [ 1.092 V]
+1.8V Voltage [ 1.822 V]
+1.2V Voltage [ 1.208 V]
+1.1V Voltage [ 1.086 V]
VTT Voltage [ 0.708 V]
+12V Voltage [12.360 V]
+5V Voltage [ 5.036 V]
+3.3V Voltage [ 3.282 V]
+5VSB Voltage [ 5.088 V]
+3.3VSB Voltage [ 3.306 V]
VBAT Voltage [ 3.132 V]
←→ Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
CPU1 Temperature
CPU1/2 Temperature [xxxºC/xxxºF]
TR1/2 Temperature [xxxºC/xxxºF]
The onboard hardware monitor automatically detects and displays the motherboard
component and CPU temperatures. Select [Ignored] if you do not wish to display
the detected temperatures.
CPU Fan1/2; Front Fan1–6 Speed [xxxxRPM] or [Ignored] / [N/A]
Rear Fan1 Speed [xxxxRPM] or [Ignored] / [N/A]
The onboard hardware monitor automatically detects and displays the speed of
CPU fans, front fans, and rear fan in rotations per minute (RPM). If the fan is not
connected to the motherboard, the eld shows [N/A].
