Asus RT-N12 Series User Manual

10
Item Description
1
Mounting hooks
Use the mounting hooks to mount your router on concrete or
wooden surfaces using two round head screws.
2
Air vents
These vents provide ventilation to your router.
Bottom panel
NOTE: Mounting the wireless router to a wall is not
recommended as it reduces wireless performance.
2
1

Asus RT-N12 Series Specifications

General

Wireless Standard	IEEE 802.11b/g/n
Frequency Band	2.4 GHz
Data Rate	Up to 300 Mbps
LAN Ports	4 x 10/100 Mbps
WAN Ports	1 x 10/100 Mbps
Operating Temperature	0 °C to 40 °C
Antenna	2 x external antennas
Encryption	64/128-bit WEP, WPA2-PSK, WPA-PSK
Security	Firewall
Firewall	SPI
Storage Temperature	-20°C to 70°C
Storage Humidity	20% to 90% RH
